- Page 1 Output module for output signals Manual Issue 1.4...
- Page 2 However, the information in this publication is updated regularly. Required corrections are contained in the following regulations or can be downloaded on the Internet. The current version is available for download on our web site www.iba-ag.com. Copyright notice ®...
-
Page 3: Table Of Contents
8.3.2 Update via ibaPDA ..................18 Module Information / Diagnostics ..............18 8.4.1 Diagnostics ....................18 8.4.2 Webinterface ....................18 iba Applications .................... 20 Configuration in ibaPDA ................20 9.1.1 General settings ..................20 9.1.2 Output Configuration ..................22 9.1.3 Reset channel errors ................... - Page 4 Manual ibaMS16xAO-10V/-20mA Technical Data ....................27 10.1 Main data ....................27 10.2 Analog outputs .................... 27 10.3 Dimensions ....................29 Support and contact ..................30 Issue 1.4...
-
Page 5: About This Manual
Note The documentation for the iba-modular system is part of the DVD that is included in delivery. The documentation of the iba-modular system comprises the following manuals: ... -
Page 6: Target Group
Manual ibaMS16xAO-10V/-20mA Target group This manual addresses in particular the qualified professionals who are familiar with han- dling electrical and electronic modules as well as communication and measurement tech- nology. A person is regarded to as professional if he/she is capable of assessing safety and recognizing possible consequences and risks on the basis of his/her specialist training, knowledge and experience and knowledge of the standard regulations. -
Page 7: Used Symbols
Manual Used symbols If safety instructions or other notes are used in this manual, they mean: The non-observance of this safety information may result in an imminent risk of death or severe injury: By an electric shock! ... -
Page 8: Introduction
Introduction The modules ibaMS16xAO-10V and ibaMS16xAO-20mA are members of the iba-modu- lar system. The modular concept is designed on the basis of a backplane. You can plug on this backplane not only the CPU, but also up to 4 input/output modules. The power supply of the I/O modules is provided by the backplane bus. -
Page 9: Scope Of Delivery
ibaMS16xAO-10V or ibaMS16xAO-20mA device 4 x 12-pin multi-pin connector Manual DVD „iba Software & Manuals“ (only for single delivery) Safety instructions Proper use The device is an electrical apparatus. It is only allowed to use the device for the following applications: ... -
Page 10: System Requirements
Manual ibaMS16xAO-10V/-20mA System requirements Hardware Central unit: ibaPADU-S-IT-2x16 or ibaPADU-S-CM (version 02.10.001 or later) Backplane unit, e. g. ibaPADU-B4S Software ibaPDA version 6.34.0 or later ibaLogic-V5 version 5.0.2 or later Note The use of ibaLogic-V5 requires the central unit ibaPADU-S-IT-2x16. If the module is used with the predecessor ibaPADU-S-IT-16, only ibaLogic-V4 can be used. -
Page 11: Connecting
Manual Connecting Note The backplane unit and the device must be connected to a protective conductor. 1. Connect all cables. 2. If all required cables are connected, connect the central unit to the power supply. 3. Switch on the central unit. -
Page 12: Device Description
Manual ibaMS16xAO-10V/-20mA Device description Views Fixing screws Operating status indicators L1… L4 Status LED L26 to L41 of the analog outputs 00 …15 Connection X1 for analog outputs 00…03 Connection X2 for analog outputs 04 … 07 Connection X3 for analog outputs 08 … 11 Connection X4 for analog outputs 12 …... -
Page 13: Indicator Elements
L3: white L4: red Normal status, no error Flashing Device error Important note When the LED L4 indicates a failure, please contact the iba support. Status of analog outputs L26 … L41 7.2.2 LED per Status Description Description channel*... -
Page 14: Overload Protection
Manual ibaMS16xAO-10V/-20mA 7.3.2 Overload protection The outputs are protected against short circuits. Nevertheless a hardware error may oc- cur, e. g. when the wiring is not correct. When there is a hardware error, e. g. overtemperature, all channels of a signal root are set to “safe state”... - Page 15 Manual Pin assignment Connection Pin Connection Analog output 00 + Analog output 08 + Analog output 00 Analog output 08 Analog output 00 Analog output 08 Analog output 01 + Analog output 09 + Analog output 01 ...
-
Page 16: Start-Up / Update
Web interface. In this case, a new update file has to be installed for the “overall release version“. If you want to get the current update file, please contact the iba support. Overall Release Version The „overall release version“... -
Page 17: Update
Important note The Web interface is available only with the central unit ibaPADU-S-IT-2x16. Start the Website of the iba-modular system in your browser and select the central unit. On the “update“ tab, click on the <Browse…> button and choose the <padusit2x16_ v[xx.yy.zzz].iba>... -
Page 18: Update Via Ibapda
Manual ibaMS16xAO-10V/-20mA 8.3.2 Update via ibaPDA Open the ibaPDA I/O Manager and choose your iba-modular system in the tree structure. On the “Diagnostics“ tab, click on the <Write firmware> button and choose the „padusit2x16_v[xx.yy.zzz].iba“ or „paduscm_v[xx.yy.zzz].iba“ update file. - Page 19 Manual „info“ tab 8.4.2.1 The „info“ tab displays general information and technical specifications of the I/O module. Figure 6: „info“ tab „notes“ tab 8.4.2.2 On the “notes“ tab, you can enter notes, e.g. for notes on wiring or on recording of changes.
-
Page 20: Iba Applications
The automatic detection requires a bidirectional FO connection from the ibaPDA com- puter to the central unit. Other documentation If you want to install the iba-modular system at first, refer to the manual of the central unit, chapter “Configuration with ibaPDA”. 9.1.1 General settings If the module is detected, click on the module in the signal tree and the „General“... - Page 21 Manual Locked True: the module can only be changed by an authorized user. False: the module can be changed by any user. Enabled Data capturing for this module is enabled. Name You can enter a name for the module.
-
Page 22: Output Configuration
Manual ibaMS16xAO-10V/-20mA Figure 10: ibaMS16xAO-10V – „Digital“ tab Channel [0…15] active Here you can activate a status signal that indicates whether the output is active. Channel […] error state Status signal indicates whether the outputs of a root are in error state. -
Page 23: Reset Channel Errors
Manual Name You can enter a name for the signal and two additional comments (click on the icon in the Name field). Expression For each output you can specify a signal using the expression builder . Signals can be linked mathematically or logically. -
Page 24: Configuration In Ibalogic-V5
Manual ibaMS16xAO-10V/-20mA Configuration in ibaLogic-V5 Other documentation Combined with ibaLogic-V5, an ibaPADU-S-IT-2x16 device can be used to realize indi- vidual signal pre-processing or stand-alone applications. You find the basic way of pro- ceeding description in the separate ibaPADU-S-IT-2x16 manual. This manual describes only the signals belonging to this module. - Page 25 Manual All available status or failure information is listed under „Inputs“. Figure 14: ibaMS16xAO-10V inputs Issue 1.4...
- Page 26 Manual ibaMS16xAO-10V/-20mA Signal Description Inputs AO_On_Ch[00..15] Channel status: 0 = channel not ready for operation 1 = channel ready for operation AO_Err_Ch[00_03…12_15] Error state of a quad root, see chapter 7.3.2. StatusIn Status information about the plugged input module (for output module without function):...
-
Page 27: Technical Data
Manual Technical Data 10.1 Main data Short description Name ibaMS16xAO-10V ibaMS16xAO-20mA Oder number 10.124150 10.124160 Description Output module with 16 Output module with 16 analog voltage outputs analog current outputs Power supply, interfaces, indicators Power supply 24 V DC, internal via backplane bus... - Page 28 Manual ibaMS16xAO-10V/-20mA Filter R/C low pass 40 kHz Output signal range -10 V to +10 V -20 mA to +20 mA ≥ 1 kΩ ≤ 500 Ohm Ω Load Output frequency Up to 40 kHz , freely adjustable Delay 8 µs + 12 µs (setting time until 90 % of the output...
-
Page 29: Dimensions
Manual 10.3 Dimensions Figure 15: Module dimensions (dimensions in mm) Issue 1.4... -
Page 30: Support And Contact
+49 911 97282-0 Fax: +49 911 97282-33 E-mail: iba@iba-ag.com Contact: Harald Opel Shipping address iba AG Gebhardtstr. 10 DE-90762 Fürth Germany Regional and Worldwide For contact data of your regional iba office or representative please refer to our Website www.iba-ag.com. Issue 1.4...
