- Page 1 Enterasys S-Series ™ Option Module Hardware Installation Guide P/N 9034461-05...
- Page 3 Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made.
- Page 4 Regulatory Compliance Information Federal Communications Commission (FCC) Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 5 It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please contact Enterasys Customer Support at +353 61 705500 (Ireland).
- Page 6 SJ/T 11363-2006 standard. This table shows where these substances may be found in the supply chain of Enterasys’ electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.
- Page 7 Safety Information Class 1 Laser Transceivers The single mode interface modules use Class 1 laser transceivers. Read the following safety information before installing or operating these modules. The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop eliminates the need for maintenance checks or adjustments.
- Page 8 2006/95/EC Manufacturer’s Name: Enterasys Networks, Inc. Manufacturer’s Address: 9 Northeastern Boulevard Salem, NH 03079 European Representative Name: Enterasys Networks Limited European Representative Address: Nexus House, Newbury Business Park London Road, Newbury Berkshire RG14 2PZ, England Conformance to Directive(s)/Product Standards: EC Directive 2004/108/EC...
- Page 9 CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc., on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program/firmware (including any accompanying documentation, hardware or media) (“Program”) in the package...
- Page 10 Agreement. 12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of this Agreement must be in writing and will not be construed as a waiver of any subsequent breach of such term or condition. Enterasys’ failure to enforce a term upon Your breach of such term shall not be construed as a waiver of Your breach or prevent enforcement on any other occasion.
- Page 11 14. TERMINATION. Enterasys may terminate this Agreement immediately upon Your breach of any of the terms and conditions of this Agreement. Upon any such termination, You shall immediately cease all use of the Program and shall return...
-
Page 13: Table Of Contents
Contents About This Guide Who Should Use This Guide ........................... xiii How to Use This Guide ............................ xiii Related Documents ............................xiv Typographical Conventions ..........................xiv Getting Help ..............................xv Chapter 1: Introduction Option Module Types and Compatibility ......................1-1 Option Module Port Options ........................... 1-2 Power over Ethernet ............................ -
Page 15: About This Guide
A brief summary of each chapter • Definitions of the conventions used in this document • Instructions regarding how to obtain technical support from Enterasys Networks. To locate information about various subjects in this guide, refer to the following table. For... Refer to... -
Page 16: Related Documents
Related Documents Related Documents Enterasys S-Series Configuration Guide and Enterasys S-Series CLI Reference Guide provide information on how to use the CLI to set up and manage the S-Series devices. These manuals can be obtained from the World Wide Web in Adobe Acrobat Portable Document Format (PDF) at the following site: https://extranet.enterasys.com/downloads/... -
Page 17: Getting Help
Getting Help Getting Help For additional support related to the S-Series or this document, contact Enterasys Networks using one of the following methods: World Wide Web http://www.enterasys.com/support Phone 1-800-872-8440 (toll-free in U.S. and Canada) or 1-603-952-5000 For the Enterasys Networks Support toll-free number in your country: http://www.enterasys.com/support... - Page 18 Getting Help xvi About This Guide...
-
Page 19: Chapter 1: Introduction
S180 Class I/O fabric modules. For a complete list of the available S-Series I/O modules and I/O fabric modules and their compatibility with S-Series option modules, refer to the S-Series datasheet at http://www.enterasys.com/products. Enterasys S-Series Option Module Hardware Installation Guide 1-1... -
Page 20: Option Module Port Options
Management You can manage the S-Series modules in which the S-Series option modules are installed either in- band or out-of-band. In-band remote management is possible using the Enterasys Networks’ ® NetSight management application or the command line interface (CLI) via Telnet. Out-of-band management is provided through the RJ45 COM (Communication) port on the front panel of the S-Series chassis using a PC, a VT terminal, or a VT terminal emulator. -
Page 21: Chapter 2: Installing The Option Module
For information about... Refer to page... Required Tools Unpacking the Option Module Installing the Option Module Connecting the Option Module to the Network LEDs 2-10 Required Tools • ESD wrist strap • Phillips screwdriver Enterasys S-Series Option Module Hardware Installation Guide 2-1... -
Page 22: Unpacking The Option Module
Store or transport the option module only in anti-static packaging. Save the bag in the event the module must be reshipped. Examine the module for damage. If any damage exists, DO NOT install the module. Immediately contact Enterasys Networks. Refer to “Getting Help”... -
Page 23: Removing The Faceplate And Top Cover From The S-Series Module
Installing the Option Module Figure 2-1 Removing the Faceplate and Top Cover from the S-Series Module Top cover Faceplate Enterasys S-Series Option Module Hardware Installation Guide 2-3... -
Page 24: Removing The Option Slot Cover
Installing the Option Module Remove the option slot coverplate by unscrewing the two screws that fasten the option module coverplate to the S-Series module. See Figure 2-2. Figure 2-2 Removing the Option Slot Cover Set the option slot coverplate aside in the event that you remove the option module and operate the module without an option module installed. -
Page 25: Installing The Poe Power Header For An Option Module With Rj45 Ports
Installing the PoE Power Header for an Option Module with RJ45 Ports Installation slot for the PoE power header PoE power header Position the option module so its connectors align with the module’s motherboard connectors. Enterasys S-Series Option Module Hardware Installation Guide 2-5... -
Page 26: Installing The Option Module
Installing the Option Module Press straight down on the option module, applying pressure directly over the connectors until they are properly seated in the motherboard connectors. See Figure 2-4. The bottom of the option module board should rest against the top of the four standoffs under the option module. -
Page 27: Securing The Option Module To The S-Series Module
This completes the option module installation. You can now install the module in an S-Series chassis. In the event that you must remove the option module from the module, see Appendix Removing an Option Module from an I/O Module. Enterasys S-Series Option Module Hardware Installation Guide 2-7... -
Page 28: Connecting The Option Module To The Network
Link Aggregation to operate properly. Before connecting the cables, refer to the Enterasys S-Series Configuration Guide for the configuration information. For details on how to obtain manuals, refer to “Related... -
Page 29: Connecting Pluggable Transceivers To The Sfp And Sfp+ Ports
To install an SFP or SFP+ pluggable transceiver in the S-Series option module: Hold the pluggable transceiver so that the connector will seat properly. Carefully align the pluggable transceiver with the port. Enterasys S-Series Option Module Hardware Installation Guide 2-9... -
Page 30: Leds
LEDs Push the pluggable transceiver into the port until the pluggable transceiver clicks and locks into place. Removing the Pluggable Transceiver To remove a pluggable transceiver from a port: Caution: Do NOT remove an SFP or SFP+ without releasing the locking tab located under the front bottom end of the SFP or SFP+ This can damage the SFP or SFP+. -
Page 31: Port Leds
Link present, port enabled, traffic is being received by the interface. None Port enabled, but no activity. (Transmit) Green (blinking) Indicates data transmission activity. Flashing frequency indicates the data rate. Yellow (solid) Fault or error (collision). Enterasys S-Series Option Module Hardware Installation Guide 2-11... - Page 32 LEDs 2-12 Installing the Option Module...
-
Page 33: Appendix A: Specifications And Regulatory Compliance
(Class A), EN 55024, EN 61000-3-2, EN 61000-3-3, AS/NZS CISPR-22 (Class A). VCCI V-3. CNS 13438 (BSMI), 2004/108/EC (EMC Directive) Environmental 2011/65/EU (RoHS Directive), 2012/19/EU (WEEE Directive), Ministry of Information Order #39 (China RoHS) Enterasys S-Series Option Module Hardware Installation Guide A-1... - Page 34 Regulatory Compliance A-2 Specifications and Regulatory Compliance...
-
Page 35: Appendix B: Removing An Option Module From An I/O Module
This procedure is also applicable to those I/O modules. Attach the anti-static wrist strap. Refer to the instructions on the anti-static wrist strap package. Place the I/O module on an anti-static pad on a sturdy, flat surface. Enterasys S-Series Option Module Hardware Installation Guide B-1... -
Page 36: Removing The Top Cover And Faceplate Of The I/O Module
Removing an Option Module Remove the eleven screws fastening the top cover and faceplate to the main board of the I/O module (five screws on top, two screws on the sides, four screws on the bottom). See Figure B-1. Set aside the top cover, faceplate, and screws for reinstallation at the end of this procedure. Figure B-1 Removing the Top Cover and Faceplate of the I/O Module Top cover... -
Page 37: Removing The Four Pan Head Screws
Keep the screws with the option module. If you install an option slot coverplate after you have removed the option module, you will need to use two of the pan head screws. Figure B-2 Removing the Four Pan Head Screws Pan head screws Option module Enterasys S-Series Option Module Hardware Installation Guide B-3... -
Page 38: Removing The Option Module From The I/O Module
Removing an Option Module With your fingers under the faceplate and on the back edge of the option module, gently rock the option module back and forth 10 to 15 times while lifting the option module straight off the I/O module motherboard connectors. See Figure B-3. -
Page 39: Removing The Poe Power Header (If Necessary
I/O module in the chassis. Reinstall the faceplate and top cover of the I/O module. You can now install the I/O module in an S-Series chassis. Enterasys S-Series Option Module Hardware Installation Guide B-5... - Page 40 Removing an Option Module B-6 Removing an Option Module from an I/O Module...
