Miranda picoLink Series Manual To Installation And Operation

12-bit sdi to ntsc/pal encoder
Hide thumbs Also See for picoLink Series:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the picoLink Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Miranda picoLink Series

Summary of Contents for Miranda picoLink Series

  • Page 2 This equipment has been tested and complies with the limits in accordance with the specifications in: FCC Part 15, Subpart B CE EN50081-1:1992 CE EN50082-1:1992. CONTACT MIRANDA For technical assistance, please contact the Miranda Technical Support centre nearest you: Americas Asia Telephone: Telephone:...

  • Page 3: Table Of Contents

    GUIDE TO INSTALLATION AND OPERATION CONTENTS page 1.0 ENC-291p SDI to NTSC ..1 /PAL Encoder 1.1 Introduction ………………………..... 1 1.2 Features .........…….. 1 2.0 Physical Layout ………………..... 2 3.0 Installation .......... 3 3.1 Power Supply .......... 3 3.2 SDI Input ……..……………....
  • Page 4 GUIDE TO INSTALLATION AND OPERATION ENC-291p...

  • Page 5: Enc-291P Sdi To Ntsc

    GUIDE TO INSTALLATION AND OPERATION 1.0 ENC-291p 12-bit SDI to NTSC /PAL Encoder 1.1 Introduction The ENC-291p is the industry’s smallest composite encoder. This product automatically detects 525-line and 625-line SDI signals conforming to the SMPTE 259M-C standard and provides a NTSC, PAL, PAL-M, or PAL-N composite output signal.

  • Page 6: Physical Layout

    GUIDE TO INSTALLATION AND OPERATION 2.0 Physical Layout Figure 2 illustrates the ENC-291p’s major parts and their locations. The video source is connected to the SDI input BNC and the encoded signal is provided by the composite output. Error status is provided by the status LED and mode settings are configured by two 3-position slide switches.

  • Page 7: Installation

    GUIDE TO INSTALLATION AND OPERATION 3.0 Installation 3.1 Power Supply The LKS-WSU power supply is used to power the ENC-291p for both 110V and 220V operation. This power supply provides a regulated +5 VDC@1A power source over an input range of 90 – 260 VAC.

  • Page 8: Operation

    4.0 Operation 4.1 Switch Settings Figure 4 shows the location of the slide switches and the status LED. Output setup and format (SW1) Normal, Y only and Test (SW2) Miranda Technologies inc. ENC-291p Made in Canada COMPOSITE picoLink SDI IN...

  • Page 9: Status Led

    For all output formats, the test signal is 75% color bars with 100% white bar. 4.2 Status LED The color of the status LED, located on top near the Miranda logo, identifies the presence of input errors and the selection of the test pattern. Possible indications are:...

  • Page 10: Specifications

    GUIDE TO INSTALLATION AND OPERATION 5.0 Specifications Input Signal: SMPTE 259M-C (270 Mbps) Cable length: 300 m (985') Belden 8281 Return loss: > 15 dB up to 270 MHz 75 Ω BNC Connector: Output Signal: NTSC-M (525/60) SMPTE 170M or PAL (625/50) ITU-R BT.470-6 PAL-M (525/60) ITU-R BT.470-6 PAL-N (625/50) ITU-R BT.470-6...
