- Page 1 DENSITÉ series IRD-3811 HD/SD MPEG Receiver/Decoder with ASI and RF Inputs Guide to Installation and Operation M837-8800-104 12 June 2014 Miranda Technologies 3499 Douglas-B.-Floreani St-Laurent, Québec, Canada H4S 2C6 Tel. 514-333-1772 Fax. 514-333-9828 www.miranda.com © 2014 Miranda Technologies...
-
Page 2: Electromagnetic Compatibility
9:00 am – 5:30 pm GMT Tel: +33 1 55 86 87 88 Tel: +86 10 5873 1814 Tel: +44 8705 004 350 Fax: +33 1 55 86 00 29 Fax: +44 8705 004 333 eurotech@miranda.com asiatech@miranda.com automationsupport@miranda.com Visit our web site at www.miranda.com IRD-3811... -
Page 3: Table Of Contents
GUIDE TO INSTALLATION AND OPERATION Table of Contents IRD-3811 HD/SD MPEG Decoder with ASI and RF inputs ............1 Using this Manual..........................1 Introduction ............................1 Features .............................. 1 Applications ............................3 Block Diagrams ........................... 4 Front Card-edge Interface ........................5 Physical Layout –... - Page 4 About AFD processing ........................45 Using the TS Probing Option ......................49 Using the video proxy streaming ....................... 49 Specifications ........................50 ANNEX 1 – Local Control Panel User Interface ................. 52 ANNEX 2 – Dolby Metadata Profiles ................... 55 IRD-3811...
-
Page 5: Ird-3811 Hd/Sd Mpeg Decoder With Asi And Rf Inputs
THIS MANUAL DESCRIBES FEATURES ASSOCIATED WITH IRD-3811 FIRMWARE VERSION 4.00 and up. 1.2 Introduction The IRD-3811 combines RF demodulation and MPEG-2 decoding of ASI transport streams to either HD or SD. It also offers processing of key video and audio parameters, and signal probing functions for feed aggregation, distribution, and monitoring applications by broadcasters and TV service providers. - Page 6 Extensive transport stream structure is displayed allowing easy identification of individual programs in an MPTS • MPTS automatic program selection mode and recovery Extensive Video Decoding • The IRD-3811 can decode signals in various resolutions extending to 1920x1080i, and at various frequencies. Output formats include: o 1920x1080i 59.94 o 1920x1080i 50 o 1280x720p 59.94 o 1280x720p 50 o 720x486i 59.94...
-
Page 7: Applications
IRD generates low-resolution H.264 video proxy and 2-channel audio streams of selected programs for monitoring 1.4 Applications • Decoding of MPEG-2 multi-program or single-program ASI transport streams • IP encapsulation of ASI transport streams • Program aggregation in TV service-provider headends IRD-3811 | 3... -
Page 8: Block Diagrams
GUIDE TO INSTALLATION AND OPERATION Block Diagrams The following block diagrams show the functionality of the IRD-3811. 4 | IRD-3811... -
Page 9: Front Card-Edge Interface
IRD-3811 Select Button Status LED Figure 1.2 Front card-edge layout 1.7 Physical Layout – IRD-3811 with Tuner and CAM modules The IRD-3811 consists of a base IRD- 3811 card with a tuner module (either ATSC or DVB-S2) and, optionally, a conditional access module (CAM). -
Page 10: Installation
2.2 Rear Panels The IRD-3811 has multiple inputs and outputs, and making space for all the necessary connectors at the rear of the frame requires a double-width rear panel. With the double-width rear panel installed, the IRD-3811 must be installed in the right-most of the two slots covered by the panel in order to mate with the panel’s connectors. -
Page 11: Installation Of The Conditional Access Module (Cam)
• HD/SD OUT 1 & 2 – SDI output, HD or SD The IRD-3811 provides two identical HD/SD SDI video outputs on BNC connectors. The SDI video signals conform to the SMPTE 292M and SMPTE 259M-C standards. The output format follows the input format. -
Page 12: Operation
3.2 Card-Edge Status LED The status monitor LED is located on the front card-edge of the IRD-3811, and is visible through the front access door of the DENSITÉ frame. The chart shows how the various error conditions that can be flagged on the IRD-3811 affect the LED status. -
Page 13: Local Control Using The Densité Frame Control Panel
3.3 Local control using the Densité frame control panel 3.3.1 Overview Push the SELECT button on the IRD-3811 card edge (Section 1.6) to assign the local control panel to operate the IRD-3811. Use the control panel buttons to navigate through the menu, as described below. -
Page 14: Remote Control Using Icontrol
3.4.1 The iControl graphic interface window The basic window structure for the IRD-3811 is shown in figure 3.2. The window identification line across the top gives the card type (IRD-3811) and the slot number where the card installed in its Densité frame. - Page 15 Format mismatch with output format (Key/Fill mode) Video/TRS error No transport stream (gray) Icon #4 – Video Sync Status OK; Locked on incoming PCR (green) Free run (yellow) No signal (gray) Icon #5 – Primary Audio status (green) No audio in program (yellow) IRD-3811 | 11...
- Page 16 Icon #8 – TS Limit No errors (green) Errors detected (red) No transport stream (gray) Icon #9 – Reference Locked to external reference • Mouse-over the icon to see a description of the reference in use (green) Reference missing (red) 12 | IRD-3811...
- Page 17 • Some of the buttons will be different depending on which model of the IRD-3811 is in use • This section can be hidden or revealed by clicking the arrow icon at the center of the left side border.
-
Page 18: The Input Panel
TS signal fails. Figure 3.3 The Input panel Output on Error Use the radio buttons to set the behavior of this IRD-3811 in the event of an input signal error. • Black – switch the output to black •... -
Page 19: Tuner Panels
GUIDE TO INSTALLATION AND OPERATION 3.4.3 Tuner panels The Tuner panel that appears will match the tuner type installed in the IRD-3811. 3.4.3.1 The Tuner ATSC panel (IRD-3811-VQ models only) This panel identifies the tuner type and demodulation type, and provides status icons for RF Signal Presence and RF Signal Lock. - Page 20 Note: the IRD-3811 may not supply enough power to operate an LNB directly – the LNB supply current is limited to 80 mA – which case the voltage from the IRD-3811 should be used to trigger an external driver that switches the LNB.
-
Page 21: The Conditional Access Panel
GUIDE TO INSTALLATION AND OPERATION The chart shows what combination of signals results in the application of which input channel to the IRD-3811 inputs: Applied DC voltage 13 V 9.75 MHz / vertical 9.75 MHz / horizontal Tone 10.6 MHz / vertical 10.6 MHz / horizontal... -
Page 22: The Asi Output Panel
Use the pulldown to select between: • Selected Input (on Input panel) • Tuner – from the on-board tuner • DVB-CI (only if DVB-S2 tuner and conditional access module are installed) Figure 3.7 ASI Output panel 18 | IRD-3811... -
Page 23: The Decoder Panel
GUIDE TO INSTALLATION AND OPERATION 3.4.6 The Decoder panel The decoder panel gives the user the resources to select the program that will be decoded by the IRD-3811 Config section: Service Select – use the pulldown to select the service from... - Page 24 Use the pulldown to select the aspect ratio scaling mode that will be used. These options are available: • • Auto • Stretch • Center Cut • Letter box • Pillar box Figure 3.10 Select AFD panel 20 | IRD-3811...
- Page 25 GUIDE TO INSTALLATION AND OPERATION 3.4.7.2 Metadata / Metadata tab This panel indicates presence and provides control of closed caption and teletext insertion on this IRD-3811. Closed Caption • • Note: for CVBS output, CC is always on, and not affected by this control Teletext - Insertion –...
-
Page 26: The Video Processing Panel
This panel reports the status of Dolby metadata associated with the two audio programs Figure 3.13 Video Output – Metadata/Dolby Status 3.4.8 The Video Processing panel The IRD-3811 includes basic proc amp functions for the analog video output. Figure 3.15 Video Processing panel 22 | IRD-3811... -
Page 27: The Audio Config Panel
Audio Embed – use the pulldown to set audio embedding ON or OFF 3.4.9.2 Status tab This tab contains text boxes and status icons that indicate the current status of the IRD-3811’s audio processing. Audio 1 and Audio 2 are shown in separate columns •... -
Page 28: The Audio Processing Panel
GUIDE TO INSTALLATION AND OPERATION 3.4.10 The Audio Processing panel 3.4.10.1 Shuffling tab The audio program inputs to the IRD-3811 are placed into the four AES channels embedded in the IRD-3811 ASI output. The placement depends on the setting made in the Decoder Operation pulldown in the Audio Config panel, Config tab. -
Page 29: The Reference Panel
Otherwise the reference is always taken from the input signal. The IRD-3811 output signals should always be genlocked to some reference source. The genlock source is selected in the Reference control panel. Use the radio buttons in the Reference Source area to select from the following options: •... -
Page 30: The Probing Panel
The time-out value for each of the probed values can be set by the user. • Double-click on the current value to open the data box, and enter a new value. Figure 3.22 TR 101 290 tab 26 | IRD-3811... - Page 31 Click on a slice of the pie; it will slide out and it’s program name in the table will be highlighted. • Mouse-over a slice and the associated Program Name will pop up. Figure 3.24 Probing panel – Pie Chart tab IRD-3811 | 27...
-
Page 32: The Test Panel
• When unchecked, the normal program signal is present at the output. • The icon at the top of the window (second from the right) shows the status of the color bars. Figure 3.26 The Test panel 28 | IRD-3811... -
Page 33: The Video / Audio Proxy Panel
Color samples : the three samples show the current selected color for the upper, middle and lower zones of the meter. Click on the color sample of a zone to open a color selection panel to choose a different color for that zone. IRD-3811 | 29... -
Page 34: The Network Settings Panel
• Output – sends transport stream IP Config This section displays the current IP settings on the right, and provides data boxes to enter new values on the left. Figure 3.30 Network Settings panel – Settings tab 30 | IRD-3811... - Page 35 On reception, FEC is automatic. Pro-MPEG FEC (D) pulldown: [OFF, 4, 5, 6,…., 19, 20] Pro-MPEG FEC (L) pulldown: (not active when OFF is selected in the FEC (D) pulldown) IRD-3811 | 31...
-
Page 36: The Factory/Presets Panel
This panel provides resources for saving, restoring and transferring the configuration settings of this IRD-3811. Load Factory The IRD-3811 maintains a “Factory Default” alignment in its memory, to which it can be restored at any time. • Click the Load Factory button to restore the card to its Factory default alignment. - Page 37 GUIDE TO INSTALLATION AND OPERATION • Click Save to store the current parameter settings and values from the IRD-3811 into the selected User Preset. The existing contents of the preset will be overwritten. Profiles This section provides resources to save and recover the entire card configuration (including user presets if desired) on an external disk, or to copy it to another IRD-3811 card.
- Page 38 The Profile column shows the same information as is shown for the current card in the Copy profile from line, i.e. • Current, User1, User2, User3, User4, User5 The Select column includes a checkbox to identify which IRD-3811 cards you wish to copy profiles into from the current card. •...
-
Page 39: The Options Panel
When the profile copy operation is complete, the Transfer Status box on the right of the Copy profile to line will indicate Succeeded against a green background 3.4.17 The Options panel This panel provides an entry point for activating the six options available for the IRD-3811. Each option is accessed on a separate tab. Frame Sync option... - Page 40 This option activates the Transport Stream probing functions of the IRD-3811. To activate this option, you must: • Obtain a licence key from Miranda Technologies Inc. • Type the licence key in the box • Click on ENABLE OPTION to enable the option’s features.
-
Page 41: The Alarm Config Panel
3.4.18 The Alarm Config panel Figure 3.41 Options panel - ETH This panel allows the alarm reporting of the IRD-3811 to be configured. The panel opens in a new window when the button is clicked, and can be resized if needed. - Page 42 All Overall alarms for which there is a Card LED alarm will be forced to match the Card LED alarm • All Overall Alarms for which there is no Card LED alarm will be forced to Disabled 38 | IRD-3811...
- Page 43 OK accepts the settings and closes the window once the card confirms that there are no errors. • Apply accepts the settings, but leaves the window open • Cancel closes the window without applying any changes, and leaves the previous settings intact. IRD-3811 | 39...
-
Page 44: The Info Panel
• Details…: Reports the Firmware version, service version, and panel version for this card Figure 3.47 Details window • Advanced…: Shows the Miranda LongID for this card. The Miranda LongID is the address of this IRD-3811 in the iControl network. Figure 3.48 Advanced window 40 | IRD-3811... - Page 45 • Remote System Administration – opens the Joining Locators data box, which lists remote lookup services to which this IRD-3811 is registered. Add: Force the iControl service for this IRD-3811 to register itself on a user-specified Jini lookup service, using the following syntax in the data box: jini://<ip_address>...
- Page 46 GUIDE TO INSTALLATION AND OPERATION When you click the button, you will be presented with a dialog allowing you to confirm your decision to reset, or to cancel the reset. 42 | IRD-3811...
-
Page 47: User Reference Guide
ASI hot-switch context. 4.2 Decoding Audio The IRD-3811 can decode 2 audio streams simultaneously. If no audio PID was previously selected or if the selected PID does not exist, the IRD automatically selects the first found audio in the corresponding PMT. -
Page 48: Mpeg Av Synchronization
The video stream may already contain XDS advisory data. If XDS data is already present, it is left untouched. No V- CHIP is generated if no XDS data is present. Closed captioning data must be present in the MPEG video stream or XDS data will not be inserted at the output 44 | IRD-3811... -
Page 49: Using The Up/Down/Cross Option
MPEG signal in full 16:9 (AFD code 8) down converted to SD 4:3 in letterbox will have the AFD flag 10 inserted to signal letterbox. Alternatively to AFD, the user can select VLI or WSS (PAL only). IRD-3811 | 45... - Page 50 GUIDE TO INSTALLATION AND OPERATION The charts below show the conversions that will be performed by the IRD-3811 when Active Format Descriptor (AFD) processing is activated by selecting AUTO using the Aspect Ratio Scaling Mode pulldown on the AFD tab of the Video Output panel.
- Page 51 (use preferred 16:9_8 flag instead) (16:9_2) (4:3_10) (16:9_2) 14:9 Pillar-box image in a 16:9 frame 14:9 Letterbox image in a 4:3 frame 14:9 Pillar-box image in a 16:9 frame (use preferred 16:9_11 flag instead) (16:9_3) (4:3_11) (16:9_3) IRD-3811 | 47...
- Page 52 14:9 in a 16:9 frame 4:3 frame (16:9_13) (4:3_13) (16:9_11) 16:9 Image shoot and protect 14:9 in a 14:9 Letterbox image in a 4:3 frame 16:9 Image shoot and protect 14:9 in a 16:9 frame 16:9 frame (16:9_14) (4:3_11) (16:9_14) 48 | IRD-3811...
-
Page 53: Using The Ts Probing Option
This may be more frequent when the frame rate selection is set to a fixed value. The streaming may not be able to match the frame rate requested. In such case, the video will freeze and restart when the data rate is below the allowed bandwidth. IRD-3811 | 49... -
Page 54: Specifications
GUIDE TO INSTALLATION AND OPERATION 5 Specifications 8VSB/QAM INPUT (IRD-3811-VQ only) Quantity/connector: One input with F-type connector, 75 ohm Tuning range: 51 MHz-858 MHz Input level: -27 dBmV to +33 dBmV QPSK/8PSK INPUT (IRD-3811-DVB-S2 only) Quantity/connector: One input with F-type connector, 75 ohm... - Page 55 ATSC PSIP Standard A/65 REFERENCE INPUT Reference input: One input with BNC connector Signal: SMPTE 170M/SMPTE 318M/ITU 624-4/BUT 470-6 black burst SMPTE 274M/SMPTE 296M tri-level synch (black) Return loss: >35 dB up to 5.75 MHz ELECTRICAL Power: 25 W IRD-3811 | 51...
-
Page 56: Annex 1 - Local Control Panel User Interface
ATSC DATE panel buttons) ATSC TIME DVB SI STATUS READY (for cards with DVB CHANNEL NAME S2 tuner only) CHANNEL NUMBER (the items in this part of the menu are for information only, MODULATION MODE 52 | IRD-3811... - Page 57 DECODE, PASSTHROUGH DOWNMIX MODE OFF*, LTRT, LORO SECONDARY AUDIO SOURCE PID List of avail PID in hexadecimal & decimal MODE DECODE, PASSTHROUGH DOWNMIX MODE LTRT, LORO DOLBY METADATA INSERTION OFF, ON INSERTION LINE 9, 10, 11, …., 20 IRD-3811 | 53...
- Page 58 NO TS INPUT ALARM LEVEL OFF, YELLOW, RED, FLASH RED ALARM REPORT NONE, GPI NO VIDEO SIGNAL ALARM LEVEL OFF, YELLOW, RED, FLASH RED ALARM REPORT NONE, GPI NO AUDIO SIGNAL ALARM LEVEL OFF, YELLOW, RED, FLASH RED 54 | IRD-3811...
-
Page 59: Annex 2 - Dolby Metadata Profiles
The chart shows the metadata parameter values that are available as Profiles 1 through 4 in the Generator Configuration section of the Metadata / Dolby tab in the Video Output iControl panel. See page 21. Profiles Metadata Parameter Dialogue Level IRD-3811 | 55... - Page 60 Lt/Rt Center Mix Level Lt/Rt Surround Mix Level Lo/Ro Center Mix Level Lo/Ro Surround Mix Level Dolby Surround EX Mode Not Indicated Converter Type Standard Standard Standard Standard Data Rate Not Indicated Not Indicated Not Indicated Not Indicated 56 | IRD-3811...
