- Page 1 FOE-871p Fiber Optic to HD/SD Converter Guide to Installation and Operation M734-9900-102 17 Mar 2009 Miranda Technologies Inc. 3499 Douglas-B.-Floreani St-Laurent, Québec, Canada H4S 1Y6 Tel. 514-333-1772 Fax. 514-333-9828 www.miranda.com © 2009 Miranda Technologies Inc.
- Page 2 This equipment has been tested and complies with the limits in accordance with the specifications in: FCC Part 15, Subpart B CE EN50081-1:1992 CE EN50082-1:1992 Contact Miranda For technical assistance, please contact the Miranda Technical Support centre nearest you: Americas Asia Telephone: Telephone:...
-
Page 3: Table Of Contents
GUIDE TO INSTALLATION AND OPERATION Table of Contents FOE-871p Fiber Optic to HD/SD Converter....... 1 1.1 Introduction................ 1 1.2 Features ................1 Overview ................2 Installation ................3 3.1 Power Supply ..............3 3.2 Fiber Input ................. 4 3.3 HD/SD Digital Video Output ..........4 Operation ................ - Page 4 GUIDE TO INSTALLATION AND OPERATION FOE-871p...
-
Page 5: Foe-871P Fiber Optic To Hd/Sd Converter
GUIDE TO INSTALLATION AND OPERATION FOE-871p Fiber Optic to HD/SD Converter Introduction The FOE-871p is a compact stand-alone solution receiving Standard Definition digital video (SMPTE 259M SDI 270 Mbps) as well as High Definition signals (SMPTE 292M up to 1.5 Gbps) through an SMPTE 297M fiber optic link. -
Page 6: Overview
GUIDE TO INSTALLATION AND OPERATION Overview Figure 2 illustrates the FOE-871p's major parts and their locations. The optical fiber input is connected using a single- mode SC connector, and the HD/SD digital video output appears on a BNC connector. Error status is provided by the status LED. Finally, the power source is connected to the lockable power connector. -
Page 7: Installation
GUIDE TO INSTALLATION AND OPERATION Installation Power Supply The LKS-WSU power supply provides power to the FOE-871p for 110 V and 220 V operation. The power supply is a regulated +5 VDC@2.4 A power source. The FOE-871p employs a mini XLR-3 connector for its power needs. -
Page 8: Fiber Input
GUIDE TO INSTALLATION AND OPERATION Fiber Input Connect an optical signal to the SC connector labeled FIBER IN. Class 1 laser product Hazards for the Operator Active optic fibers emit radiation invisible to the naked eye. Never look directly at the end of an active optic fiber. Caution Although not considered overly dangerous for the eye, avoid accidental exposure to the optical beam... -
Page 9: Operation
GUIDE TO INSTALLATION AND OPERATION Operation There are no operating controls on the FOE-871p. Status LED The bi-colored status LED, located next to the BNC output connector, is provided to identify any input errors. The following situations are flagged: No DC power Off: Laser light detected with valid SDI / HD-SDI Green:... -
Page 10: Specifications
GUIDE TO INSTALLATION AND OPERATION Specifications Optical Input Signal: Optical Laser Wavelength: 1310 nm and 1550 nm Sensitivity: -16 dB Fiber type: Single Mode Connector: Optical SC/PC Electrical Output Signal: SMPTE 259M-A-C (143, 270 Mbps) SMPTE 292M (1.485 Gbps and 1.485/1.001 Gbps) SMPTE 305M (SDTI) SMPTE 310M (5Mbps to 40 Mbps)
