- Page 1 DENSITÉ series SCO-1421 Intelligent ASI Change-Over with Probing Guide to Installation and Operation M937-9900-103 4 October 2013 Miranda Technologies 3499 Douglas-B.-Floreani St-Laurent, Québec, Canada H4S 2C6 Tel. 514-333-1772 Fax. 514-333-9828 www.miranda.com © 2013 Miranda Technologies...
- Page 2 GUIDE TO INSTALLATION AND OPERATION Electromagnetic Compatibility This equipment has been tested for verification of compliance with FCC Part 15, Subpart B requirements for Class A digital devices. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
-
Page 3: Table Of Contents
GUIDE TO INSTALLATION AND OPERATION Table of Contents SCO-1421 Intelligent ASI Change-Over with Probing ............1 Introduction ............................1 Features .............................. 1 Block Diagram ............................. 2 Front Card-edge Interface ........................2 Installation ..........................3 Unpacking ............................3 Installation in the Densité frame ......................3 Rear Panel Connectors ........................ - Page 4 GUIDE TO INSTALLATION AND OPERATION SCO-1421...
-
Page 5: Sco-1421 Intelligent Asi Change-Over With Probing
GUIDE TO INSTALLATION AND OPERATION 1 SCO-1421 Intelligent ASI Change-Over with Probing 1.1 Introduction The SCO-1421 is a 2x1 intelligent ASI change-over with built-in MPEG-TS probing. Changeovers are performed electronically by the SCO-1421’s internal router. In the event of a power failure, the signal is protected by relays fitted on the rear module, maintaining the integrity of the selected signal at the output. -
Page 6: Block Diagram
GUIDE TO INSTALLATION AND OPERATION Block Diagram The following block diagram shows the functionality of the SCO-1421. Figure.1.1 Functional block diagram SCO-1421 1.4 Front Card-edge Interface The front card-edge of the SCO-1421 incorporates two elements: • Status LED (see section 3.3) •... -
Page 7: Installation
GUIDE TO INSTALLATION AND OPERATION 2 Installation 2.1 Unpacking Make sure the following items have been shipped with your SCO-1421. If any of the following items are missing, contact your distributor or Miranda Technologies Inc. • SCO-1421 Intelligent ASI Change Over with Probing •... - Page 8 GUIDE TO INSTALLATION AND OPERATION When constructing and using an external GPI box, be aware of the following: The SCO-1421 card monitors the external power supply voltage on the GPI input. If the voltage is less than 4V (per relay datasheet), an alarm will be raised. When a GPI INPUT is triggered while the card is operating in auto mode, the card changes to manual mode and switches to the input selected by the GPI.
-
Page 9: Operation
GUIDE TO INSTALLATION AND OPERATION 3 Operation 3.1 Getting Started The switch mode is set to AUTO by default which means the card will automatically switch to the input with the less errors based on the error configuration that has to be done in the ALARM tab. Don’t forget to change this setting if you don’t want the card to switch by itself. -
Page 10: Local Control Using The Densité Frame Control Panel
GUIDE TO INSTALLATION AND OPERATION LED Status Flashing Error Condition Green Yellow No errors TS Presence Input 1 TS Presence Input 2 Transport ID Mismatch Input 1 Transport ID Mismatch Input 2 Total Bit Rate Input 1 ... -
Page 11: Menu For Local Control
GUIDE TO INSTALLATION AND OPERATION The local control panel displays a menu that can be navigated using the four pushbuttons located beside the display. The functionality of the pushbuttons is as follows: [+] [–] Used for menu navigation and value modification [SELECT] Gives access to the next menu level. -
Page 12: Remote Control Using Icontrol
GUIDE TO INSTALLATION AND OPERATION 3.5 Remote control using iControl The operation of the SCO-1421 may be controlled using Miranda’s iControl system. • This manual describes the control panels associated with the SCO-1421 and their use. • Please consult the iControl User’s Guide for information about setting up and operating iControl. In iControl Navigator or iControl Websites, double-click on the SCO-1421 icon to open the control panel. - Page 13 GUIDE TO INSTALLATION AND OPERATION Icon 3 – ASI 2 presence • A: Green – ASI IN locked • B: Red – No ASI IN detected Icon 4 – Bypass Mode Status • A: Bypass not active – SCO-1421 in operation •...
-
Page 14: The Switch Panel
GUIDE TO INSTALLATION AND OPERATION 3.5.2 The Switch panel The graphic at the top of the panel identifies the input that is currently selected, and indicates the validity of both inputs by the color of their icons. The status of the four GPI inputs is shown below the graphic. These inputs select the operating mode when activated. -
Page 15: The Preview Output Panel
GUIDE TO INSTALLATION AND OPERATION In the Auto Switch Config area, select the Auto Switch mode of operation: • Switch To: switches to input 2 when the alarm conditions trigger a switch. NOTE that a return to input 1 can only be made in the Manual mode. -
Page 16: The Alarms Panel
GUIDE TO INSTALLATION AND OPERATION e Alarms 3.5.4 panel The SCO-1401 continuously monitors the condition and status of the input signals it is processing. The information is used to decide whether the input must be switched in Auto mode. It is also used to flag the status of the card in the iControl system. - Page 17 GUIDE TO INSTALLATION AND OPERATION TS – TS signal presence This error is always ENABLED and the level set to 1, 2 or OFF. The factory default value is level 1. Use the slider to set the duration for which the error must continuously exist before the alarm is flagged.
- Page 18 GUIDE TO INSTALLATION AND OPERATION TS – PAT Presence This error is generated if the PAT (Program Association Table) of the input transport stream is continuously absent for a period greater than the time set in the Duration data box. •...
- Page 19 GUIDE TO INSTALLATION AND OPERATION TS – SI Tables Presence (Only available when the Advanced Probing option is enabled) This error is generated if the Service Information tables in the input transport stream service that has been selected for probing are continuously absent for a period greater than the time set in the Duration data box.
- Page 20 GUIDE TO INSTALLATION AND OPERATION Bit Rate – PID n Bit Rate (Only available when the Advanced Probing option is enabled) This error is generated if the bit rate for a specific PID in the input transport stream is continuously outside a specified range of values for a period greater than the duration set in the data box.
- Page 21 GUIDE TO INSTALLATION AND OPERATION TR 101 290 – 1.1 TS_sync_loss This alarm is set if the transport stream synchronization is lost. This is the same as the Transport Stream Presence error in the TS tab, and the Level is fixed to the value set there. It is shown here because it is included in the TR 101 290 set.
- Page 22 GUIDE TO INSTALLATION AND OPERATION TR 101 290 – 1.3c PAT_scrambling_error (Only available when the Advanced Probing option is enabled) An error occurs if the s crambling_control_field is not 00 for the PAT PID ( 0x0000). An error is reported at the first scrambling error and the error will remain for few seconds…...
- Page 23 GUIDE TO INSTALLATION AND OPERATION TR 101 290 – 1.3a PAT_error_2 (Only available when the Advanced Probing option is enabled) An error occurs if the PAT PID (0x0000) does not occur for at least the time specified by Repetition Rate slider. The error will remain for few seconds after the PAT returns.
- Page 24 GUIDE TO INSTALLATION AND OPERATION TR 101 290 – 1.5a PMT_error_2 (Only available when the Advanced Probing option is enabled) This error occurs if a PMT that is part of a service selected for probing (see TS tab…) is not present for the time specified by the Repetition Rate slider.
- Page 25 GUIDE TO INSTALLATION AND OPERATION TR 101 290 – 1.6 PID_error (Only available when the Advanced Probing option is enabled) This error occurs when there are PIDs with no associated datastream This is the same as the Service Presence error in the TS tab, and the Level is fixed to the value set there.
- Page 26 GUIDE TO INSTALLATION AND OPERATION TR 101 290 – 2.2 CRC_error (Only available when the Advanced Probing option is enabled) The CRC check for the CAT, PAT, PMT, NIT, EIT, SDT and TOT indicates whether the content of the corresponding table is corrupted.
- Page 27 GUIDE TO INSTALLATION AND OPERATION TR 101 290 – 2.3b PCR_discontinuity_indicator (Only available when the Advanced Probing option is enabled) The PCR_discontinuity_indicator_error is set in the case that a discontinuity of the PCR values occurs that has not been signaled appropriately by the discontinuity indicator. An error will only be flagged if the error rate exceeds the tolerance set using the slider, over the range 0 to 10 errors/sec.
- Page 28 GUIDE TO INSTALLATION AND OPERATION TR 101 290 – 2.5 PTS_Error (Only available when the Advanced Probing option is enabled) The Presentation Time Stamps (PTS) should occur at least every 700 ms. They are only accessible if the TS is not scrambled. An error will only be flagged if the timeout period of the PTS exceeds the tolerance set using the slider, over the range 20 to 5000 msec.
- Page 29 GUIDE TO INSTALLATION AND OPERATION TR 101 290 – 2.6b CAT_error (Only available when the Advanced Probing option is enabled) This alarm is triggered when a section with table_id other than 0x01 (i.e. not a CAT) is found on PID 0x0001, which is reserved for CAT tables.
-
Page 30: The Probing Panel
GUIDE TO INSTALLATION AND OPERATION 3.5.5 The Probing panel 3.5.5.1 TS tab In this panel, view the status of the transport stream on each of the two inputs, and a list of all 12 services available to probe on each input. Input Status: The status of the transport stream on each input is indicated by these parameters: •... - Page 31 GUIDE TO INSTALLATION AND OPERATION 3.5.5.3 PID tab The panel displays a list of all PIDs in the services selected for probing within the transport stream. A status icon is shown for the service itself, to the right of the service name, and an icon is shown for each PID.
-
Page 32: The Options Panel
GUIDE TO INSTALLATION AND OPERATION 3.5.5.5 TR 101 290 tab This tab shows the current status of each of the tests against the TR 101 290 standard (green or red status indicator, plus error message), plus the number of errors that have occurred since the counter was last reset. -
Page 33: The Factory / Presets Panel
GUIDE TO INSTALLATION AND OPERATION 3.5.7 The Factory / Presets panel The SCO-1421 maintains “Factory Default” settings in its memory, to which it can be restored at any time. Click the Load Factory button to restore the card to its Factory default settings. - Page 34 GUIDE TO INSTALLATION AND OPERATION Copy Profile From: This line shows this SCO-1421 card, and identifies it by App server, Densité frame and slot number, card type and firmware version. The Profile column has a pulldown that allows you to select which profiles you will work with, and gives these choices: •...
-
Page 35: The Alarm Config Panel
GUIDE TO INSTALLATION AND OPERATION The Select column includes a checkbox to identify which SCO-1421 cards you wish to copy profiles into from the current card. • For convenience, a Select all checkbox is provided in the column header Click Copy to copy the selected profiles from this card into the selected other SCO-1421 cards •... - Page 36 GUIDE TO INSTALLATION AND OPERATION • If the Overall alarm contribution is selected as Disabled, the GSM alarm contribution can be set to any available value • If the Overall alarm contribution is selected as any level other than disabled, the GSM contribution is forced to follow the Overall Alarm.
- Page 37 GUIDE TO INSTALLATION AND OPERATION Copy to other cards Click this button to open a panel that allows the alarm configuration set for this card to be copied into another SCO-1421 card. • Select one or more destination cards from the list in the window by clicking in the checkboxes, or all of them by clicking in the All checkbox...
-
Page 38: The Info Panel
GUIDE TO INSTALLATION AND OPERATION 3.5.9 The Info panel When the SCO-1421 is included in an iControl environment, certain information about the card should be available to the iControl system. The user can enter labels and comments that will make this card easy to identify in a complex setup. This information is entered via the Info control panel. - Page 39 GUIDE TO INSTALLATION AND OPERATION • Remote System Administration – opens the Joining Locators data box, which lists remote lookup services to which this SCO-1421 is registered. Add: Force the iControl service for this SCO-1421 to register itself on a user-specified Jini lookup service, using the following syntax: jini://<ip_address>...
-
Page 40: Specifications
4 Specifications ASI INPUTS (2) SIGNAL EN50083-9 (V2:3/98) DVB ASI DATA BIT RATE 213 Mbps CABLE LENGTH 300 m (985’) Belden 1694A at 270Mbps TS PACKET LENGTH 188/204 byte packets RETURN LOSS > 15dB up to 270Mbps CONNECTORS ASI OUTPUTS (2) -
Page 41: Annex - Sco-1421 User Interface
GUIDE TO INSTALLATION AND OPERATION ANNEX – SCO-1421 User Interface STATUS REAR TYPE GENERAL STATUS HARDWARE FAILURE BYPASS ENABLED BACKUP USED MANUAL MODE ON ATSC / ASI / ISO13818-1 TS PRESENT / NO INPUT INPUT1 STATUS # of bytes in TS (188/204) Total bit rate VALUE Transport ID VALUE Error messages from alarms (see ALARM CONFIG below)
