Myo Plus Quick Guide
Use the following steps to connect the Myo Plus system to an iOS or Android app for training and
adjustments. These instructions are intended for Myo Plus qualified Prosthetists. Please see the full
course for detailed information on all features and functions.
Step 1:
Download App
- Download the Myo Plus App to
- Open the App
- Turn-on the Myo Plus system by
Step 2:
Pair Myo Plus to your smart device
- On the main menu, click on
- Add a new connection by
- Enter the unique PIN code found
- If Bluetooth pairing request
- The app is now successfully
your smart device (Apple App
Store, or Google Play)
holding down the charging
port until 1 beep is heard and
green light appears
Bluetooth Connections
clicking on the
icon. If
Bluetooth is deactivated on your
device, confirm the Bluetooth
request with
ALLOW.
Select the
Serial Number of the system. It
is printed on the PIN card that
came with the system
on the card that comes with the
system
pops up, confirm with
OK
connected to the Myo Plus
system, and the Spider Plot is
displayed
Step 3:
Log-in as Clinician
- On the main menu, click on
- Enter Username and Un-lock
- Now create your own unique
Step 4:
Orientation of Myo Plus Cuff on limb
Right
Orient the electrode pairs evenly around the limb; pairs 1
and 8 should be on either side of the ulna, not directly on
it. Put electrode pair 1 to the lateral aspect of the ulna,
pair 8 to the medial aspect.
"Login" Bluetooth Connections
PIN
These are provided to you at the
time of qualification for Myo Plus
password. This will be used in
the future to access clinician
mode
Left
