ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Qty Designator
2 R1, R2
2 R3, R4
2 R6, R7
2 C1, C2
4 C3, C4 , C10, C11
4 C6, C7, C8, C9
2 C12, C13
2 L1, L2
3 B1, B2, B3
5 S1 (S1A, S1B, S1C, S1D, S1E)
1 J1
1 J2
1 U1
3 HD2, HD3, HD4
1 HD1
1 TB1

ORDERING GUIDE

Model
1
SSM2301-EVALZ
1 Z = RoHS Compliant Part.
Description
Resistor, 2.00 kΩ, 1/10 W, 1%, 0603, SMD
Resistor, 100 Ω, 1/10 W, 1%, 0603, SMD
Resistor, 100 kΩ, 1/10 W, 1%, 0603, SMD
Capacitor, ceramic, 220 nF, 50 V, Y5V, 0603
Capacitor, ceramic, 100 pF, 6.3 V, X7R, 0402
Capacitor, ceramic, 1 nF, 5%, 50 V, X7R, 0402
Capacitor, ceramic, 10 μF, 6.3 V, X5R, 0603
Inductor, 3.3 μH, type D62LCB SMD
Filter chip, 220 Ω, 2 A, 0603
Switch, DIP, top slide, 5-position, SMD
Audio connectors, 3.5 mm, SMT
DC power connectors, 2 mm, SMT power jack
Filterless high efficiency, mono 1.4 W, Class-D audio
amplifier
Connector header 2-position, 0.100" SGL gold
Connector header 3-position, 0.100" SGL gold
Terminal block, 3.5 mm, 4-position PCB
Description
Evaluation Board

ESD CAUTION

Rev. 0 | Page 7 of 8
EVAL-SSM2301
Supplier Supplier Part No.
Digi-Key RHM2.00KHTR-ND
Digi-Key RHM100HTR-ND
Digi-Key RHM100KHTR-ND
Digi-Key 490-1569-2-ND
Digi-Key 04026C101KAT2A-ND
Digi-Key 478-3661-2-ND
Digi-Key PCC2395TR-ND
Digi-Key A918CY-3R3M
Digi-Key 490-3992-2-ND
Digi-Key CKN6074-ND
Mouser 806-STX-3500-3N
Mouser 806-KLDX-SMT20202A
Analog Devices SSM2301CPZ-REEL7
Digi-Key SAM1029-02-ND
Digi-Key SAM1029-03-ND
Digi-Key ED1516-ND
