Environment

Environment
General
Delta Media Servers should be operated in a clean, dry, dust-free area.
·
The server is intended for operation in benign environments; that is, not subject to corrosive or explosive
·
atmospheres, moisture or flammable gases. The server is non-protected against ingress of liquid (IPx0).
The server is not designed to be subject to excessive mechanical shock or vibration.
·
Only used at altitude not exceeding 2000 m
Only used in not-tropical climate regions
Thermal
Do not block any of the server's air vents and ensure the ambient temperature around the server is
compatible with the environmental characteristics stated below.
Particularly when mounted in a rack cabinet with front or rear doors the ambient temperature around the
server may be higher than the ambient room temperature.
Pico servers can be mounted vertically using the optional VESA mounting plate, but care must be taken that
hot air from the rear panel is not drawn back in at the front. Do not mount with the front panel uppermost.
Electrical
Before connecting power to the server, ensure that electricity supply is compatible with the electrical ratings
stated on the server's product label. The server shall not be connected to an IT (unearthed neutral) power
distribution system and the mains socket-outlet used shall connect to the building installation ground.
The server is connected to and disconnected from the mains supply with the IEC 60320 power connector on
the rear of the unit.
Pico servers must only be used with the 7thSense-supplied DC power blocks. The power supply unit is
connected to, and disconnected from, the mains supply with an IEC 60320 power connector.
The low voltage output is connected to the labelled rear socket of the unit, where the lead
can be secured to the chassis with the clip provided. Only use the 19 VDC power supply unit
that is supplied by 7thSense with the Pico unit. Failure to do so may damage the Pico and invalidate any
warranty.
