Front Panel Control and Display

Front Panel Control and Display
The Delta Front Panel is controlled by the Delta Monitor application, and can also be accessed via the
web interface.
On Delta 1.5 servers the functionality is limited. Delta 2 added a significant amount of additional functionality.
Delta 2.4 saw more software changes to allow for NICs to be modified in all servers (including Nano) without
having to enter Service Mode, and with further options for NIC modification throughout. From DeltaMonitor
v. 3.0.30 a Konami code was added to lock the front panel controls, and from v.3.0.31, the DeltaGUI
connection was added, and warning of licence expiry.
Terminology
Embedded Server – This refers to the Operating system on the server. The embedded servers include: Nano,
Nano4K and Duo II pre-2016, and Nano1, Nano2, Nano3, Nano4K in the 2016 and later server range. (For
further information see the
Pico servers
Pico servers do not share the same front panel controls, and have a single LED indicator on the left:
Green
Amber
/ Flashing green and amber
Hardware Operation
Service Mode Section.)
The Pico is on and Delta is running.
The server is on and Delta is not running.
Server identification state – the IP has been called externally with a
GPIO_ID command (works only when Delta is running). after 15
seconds reverts to green. The DeltaFinder utility operates this mode.
38
