- Page 1 Delta Media Server Setting up VIOSO to work with Delta Media Server User Guide M365-1...
- Page 2 Setting up VIOSO to work with Delta Media Server : User Guide Trademark Information Delta Media Server is a trademark of 7thSense Design Ltd. Brand or product names may be registered trademarks of their respective owners. Windows is a registered trademark of Microsoft Corporation in the United States and other countries.
-
Page 3: Table Of Contents
Contents Installation and Setup VIOSO Integrate Load Mapping into Delta Media Server Document Information Index Setting up VIOSO to work with Delta Media Server © 2020 7thSense... -
Page 4: Installation And Setup
Installation and Setup Installation and Setup This guide takes you through using VIOSO autoalignment software with an IDS camera for aligning a flat screen projection, exporting alignment data as MPCDI and importing it into Delta. Whilst the worked example here is a flat-screen, VIOSO autoalignment is available for any projection. -
Page 5: Vioso Integrate
A. Select Displays and Camera 1. Launch VIOSO Integrate from the desktop. 2. On opening, you may see a prompt stating ‘Overlap detected’. Click Yes. 3. Select Calibrate to begin. Setting up VIOSO to work with Delta Media Server © 2020 7thSense... - Page 6 VIOSO Integrate 4. Select single client calibration and then you should see a window like this: 5. Select ‘display split’. Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
- Page 7 VIOSO Integrate 6. Set the number of vertical parts/horizontal parts to match the Eyefinity or Mosaic group and apply: Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
- Page 8 7. Select all displays for the calibration and the screen type for Setup method: 8. Set the projector arrangement to match the arrangement on screen. 9. Set any Extended Options as desired, or use defaults. Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
- Page 9 VIOSO Integrate 10. Adjust the camera rotation as necessary under Options > Image Processing: Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
- Page 10 VIOSO Integrate 11. Adjust the camera zoom under the Format menu to zoom into the screen shape, which reduces processing time: Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
- Page 11 VIOSO Integrate 12. Draw a mask around the screen area. Single click to set the first point, double click to end a line making sure to overlap your lines: Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
- Page 12 VIOSO Integrate 13. Fill the unwanted region of the image with the paint bucket tool and optionally save the mask: 14. Select Next Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
- Page 13 VIOSO Integrate B. Geometric Correction 1. If asked which set of geometric correction data source to use, select Method: ‘Perform new scan’. Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
- Page 14 2. If the initial result does not yield bright green circles, press back to adjust the noise filter, otherwise, proceed to step 5, ‘Adjust geometry scan inspection options’. Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
- Page 15 VIOSO Integrate 3. Adjust the threshold and thickness until you have thin, distinct lines across your entire projected surface and click Next. Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
- Page 16 VIOSO Integrate 4. Adjust the sliders to change the circle size and spacing until you have distinct green circles, then select Next. Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
- Page 17 – adds unwanted waviness on corners) for arbitrary shapes (but still the shape needs to be continuous [no corners]). g. Number of points that must be extrapolated (-1 = whole display). Check if needed area is covered by projection. Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
-
Page 18: Load Mapping Into Delta Media Server
2. Select the target display (not the individual displays) and your desired format from the dropdown. 3. Tick ‘Individual split export’. 4. Tick ‘Virtual content rects’ in case you want to let VIOSO do the slicing; you’ll find a ~_def.txt containing optimal content size and scanouts. - Page 19 DeltaGUI. These are the MPCDI regions (Delta: channels). You need to know how these regions correspond to your Delta channel numbers so that you can match them up. Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
- Page 20 Load Mapping into Delta Media Server Configure Delta to Use MPCDI Enable MPCDI and check the required/available data, in DeltaGUI > Preferences > Startup & File Load: Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
- Page 21 Assign your output channels to MPCDI regions by selecting in turn the Delta output channel (top of left panel), then the MPCDI region. You should see the channels come live in Channel View, outlined in the colour of the channel. Setting up VIOSO to work with Delta Media Server © 2020 7thSense...
-
Page 22: Document Information
Document Information Document Information Date Document Software Revision Details Author/Editor edition version June 2019 Delta 2.6 New release Andy Robinson Setting up VIOSO to work with Delta Media Server © 2020 7thSense... -
Page 23: Index
Index VIOSO autoalignment assign regions to channels calibrate configure Delta export MPCDI geometric correction import mapping into Delta installation and setup Setting up VIOSO to work with Delta Media Server © 2020 7thSense... - Page 24 E: info@7thsense.one W: 7thsense.one 7thSense Design Ltd 7thSense Design LLC, Michigan 7thSense Design LLC, Orlando 2 The Courtyard, Shoreham Road 332 E Lincoln Ave 4207 Vineland Rd Upper Beeding Suite 100 Suite M1 Steyning Royal Oak, MI 48067 Orlando, FL 32811 West Sussex BN44 3TN T: +44 (0) 1903 812299...
