Air Filter Replacement

Air Filter Replacement
A user-serviceable air filter is located on the server's front panel. It is important to remove and clean or
replace the filter periodically to avoid overheating. Delta Servers are supplied with one spare filter pad, others
can be supplied by 7thSense. Servers should not be run without filters, since accumulations of dust inside the
server can affect performance.
Before removing any filter, power the server down. This will avoid disturbing dust, which can then be drawn
back into the server.
Proton, Nucleus, Infinity
Pull down the filter door, and push the carrier forward evenly against the spring clips. Note the orientation of
the carrier with the magnetic catch spot at the top.
Remove, clean or replace the foam, noting the orientation of the cutouts.
Relocate the bottom of the carrier, push against the springs and relocate into place.
