7th Sense NanoR Hardware User's Manual

Specification
Environmental Characteristics
Temperature
Humidity (non-condensing)
Altitude
Product Electrical Rating
NanoR 100-240V, 3-1.3A, 60-50Hz
NanoSDI 100-240V, 4.5-2A, 60-50Hz
Proton 100-240V, 7-3.5A, 60-50Hz
Nucleus 100-240V, 10-5A, 60-50Hz
Infinity 100-240V, 10-5A, 60-50Hz
End of Service Life
Dispose of the equipment and any components in accordance with all local and national
safety and environmental requirements.
Regulatory Compliance Statements
FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with this user guide, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
European Union
This is a Class A product. In a domestic environment, this product may cause radio interference, in
which case the user may be required to take adequate measures.
7thSense Design Ltd : 2 The Courtyard, Shoreham Road, Upper Beeding, BN44 3TN, UK
www.7thsense.one
Copyright © 7thSense Design Ltd : M282-6
Operating Non-operating
+15 to +30 ° C -10 to +50 °C
10 to 90% 5 to 95%
<2000 m <10000 m
Weight (kg)
Dimensions (H × W × D)
4.5 1U × 483 mm × 241 mm
6 1U × 483 mm × 321 mm
13 2U × 483 mm × 545 mm
15
3U × 483 mm × 497 mm
21 3U × 483 mm × 603 mm
Delta Media Server
Hardware User Guide
For NanoR, NanoSDI, Proton, Nucleus, Infinity
Customer Support Portal: https://portal.7thsense.one
Support
If your Delta Media Server was purchased through one of our regional distributors, please contact
your supplier directly for support.
Visit our customer support portal where you can find a wide range of support documentation and
video tutorials, together with contact information.
Warranty
Standard warranty is 24 months, return-to-supplier. Please contact your supplier if you require an
extended warranty. Please ask for instructions and request authorisation before returning a server
to your supplier.
Operating Instructions
Operating instructions for your server can be found in the Online User Guides section of the
customer support portal.
Handling and Installation
Unpacking
Unpack your server carefully onto a clean and level surface and examine it for any signs of transit
damage. Contact your supplier immediately if anything appears to be damaged, or any parts
missing. Please retain all packaging in case of future need to return a server.
Lifting
Delta Media Server weight depends on model, the weight is stated below and on the server's
product label. Larger servers may require a two-person lift, especially when manoeuvring them into
a rack. Observe your internal manual handling recommendations to avoid injury.
Rack mounting
Delta 2U and 3U servers are supplied with rack mount slide rails and fixings, installation
instructions are included with the slide rails.
Delta 1U servers should be installed in a rack using a minimum of an M6 rack mount bolt in each of
the top and bottom mounting holes on each side of the server's front panel.
Ensure that each server is properly secured to the rack cabinet.
Rack stability warnings:
• Ensure the rack is stable (e.g. bolted to the floor) before sliding out the server.
Do not place objects on equipment projecting from a rack (e.g. do not use as a shelf).
•
• Only slide out one piece of equipment from the rack at a time.
August 2019
