Removable Power Supply

Removable Power Supply
Delta Media Servers (3U models only – Nucleus and Infinity) are fitted with a removable power supply unit
(PSU). This can be replaced as follows:
To remove: Power down the server and then remove the IEC320 power connector from the server's PSU.
·
Press the PSU's release tab and pull the handle to slide the power supply out of the server:
·
To replace: Slide the replacement power supply into the server until it fully clicks home.
·
Refit the IEC320 power connector and power on the server.
·
Warning: The IEC320 power connector should never be inserted into the PSU when the PSU is not
fitted in a server.
