Summary of Contents for Keysight Technologies 16453A
- Page 1 Keysight 16453A Dielectric Material Test Fixture Specification and Service Manual...
- Page 3 Agilent 16453A Dielectric Material Test Fixture Speci cation and Service Manual Agilent Part No. 16453-90010 Printed in JAP AN September 2000 Fourth Edition...
- Page 4 Notice The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of the Agilent Technologies.
- Page 5 Manual Printing History The manual printing date and part number indicate its current edition. The printing date changes when a new edition is printed. (Minor corrections and updates that are incorporated at reprint do not cause the date to change.) The manual part number changes when extensive technical changes are incorporated.
- Page 6 Safety Summary The following general safety precautions must be observed during all phases of operation, service, and repair of this instrument. Failure to comply with these precautions or with speci c WARNINGS given elsewhere in this manual violates safety standards of design, manufacture, and intended use of the instrument.
- Page 7 Operating Precaution Do not exceed the operating input power, voltage, and current level and signal type appropriate for the instrument being used, refer to your instrument's operation manual. Caution Electrostatic discharge ( esd ) can damage the highly sensitive microcircuits in your instrument.
- Page 8 Limitation Of Warranty The foregoing warranty shall not apply to defects resulting from improper or inadequate maintenance by Buyer, Buyer-supplied software or interfacing, unauthorized modi cation or misuse, operation outside the environmental speci cations for the product, or improper site preparation or maintenance. No other warranty is expressed or implied.
- Page 9 Safety Symbols General de nitions of safety symbols used on equipment or in manuals. Instruction manual symbol: the product is marked with this symbol when it is necessary for the user to refer to the instruction manual in order to protect against damage to the instrument.
- Page 10 APC-7 R is a U.S. registered trademark of the Bunker Ramo Corporation. viii...
-
Page 11: Table Of Contents
Contents General Information Introduction ....... . . Product Description ......Applicable Instrument . - Page 12 1-1. Applicable Dielectric Material Size Using with 16453A ... . 2-1. 16453A Contents ......
-
Page 13: General Information Introduction
The 16453A is a xture for measuring the permittivity of dielectric materials. Applicable Instrument The 16453A has been designed to operate speci cally with the 4291A RF Impedance/Material Analyzer equipped with the Option 002 (which provides the permittivity measurement function for dielectric material). -
Page 14: Speci Cations
This section lists the complete 16453A speci cations. These speci cations are the performance standards and limits against which the 16453A is tested. When shipped from the factory, the 16453A meets the following listed speci cations. For the speci cations when used with the 4291A, see the 4291A RF Impedance/Material Analyzer Operating Manual Set . -
Page 15: Initial Inspection Introduction
Inspect the shipping container for damage. Keep the shipping materials until the inspection is completed. Verify that the shipping container contains everything listed in Table 2-1. Inspect the exterior of the 16453A for any signs of damage. Initial Inspection... -
Page 16: Repackaging The Test Fixture For Shipment
xture in heavy paper and pack in anti-static plastic packing material. Use sucient shock absorbing material on all sides of the 16453A to provide a thick, rm cushion and to prevent movement. Seal the shipping container securely and mark it FRAGILE . -
Page 17: Service Introduction
Service Introduction This chapter provides service information for the 16453A Dielectric Material Test Fixture. Replaceable Parts Table 3-1, Table 3-2, and Table 3-3 identify the replaceable parts. The parts listed in these tables can be ordered from your nearest Agilent Technologies oce. Ordering information should include the Agilent Part number and the quantity required. - Page 18 Table 3-1. Replaceable Parts List (Upper Part) Reference Agilent Part Number Qty. Description Designator 16190-09001 Plate 3030-0007 Screw SET4-40 16453-23004 Screw 16453-01215 Latch Plate 1460-2384 Spring 16453-01211 Plate 16453-23003 Dial 16453-24003 Screw 16453-04001 Cover 0515-0914 Screw M3 L6 16453-23001 Knob Shaft 16453-23002 Sleeve 3030-0285...
- Page 19 Table 3-2. Replaceable Parts List (Lower Part) Reference Agilent Part Number Qty. Description Designator 0515-0914 Screw M3 L6 16453-24011 Flange 1250-0816 Contact 16453-60001 Bead Assembly 16453-24018 Electrode 1480-0739 Spring Pin 0515-0914 Screw M3 L6 16092-21010 16453-01212 Plate 16453-08001 Spring 16453-01214 Plate 16453-20012 Base...
-
Page 20: Parts Replacement Procedures
Consists of load plate, case, and thickness label. These parts are not shown in this gure. Parts Replacement Procedures This section provides removal and replacement procedures for the 16453A. Note In this section, numbers quoted by \" correspond to Reference Designators in the Replaceable Parts Lists (Table 3-1, Table 3-2, and Table 3-3). -
Page 21: Replacement Procedure
5. Remove plate \6." 6. Remove button \17" and spring \16." 7. Detach the lower part from the upper part by removing the two \33" screws from the bottom of the assembly. Lower Part Disassembly 8. Remove plate \31." 9. Remove plate \29" and spring \30" by removing the two \27" screws from plate \31." 10. -
Page 22: Functional Test
Functional Test This section provides the functional test procedure to check the 16453A's performance. The functional test can be used for post repair function veri cation. Fixture Impedance Check 1. Perform the 4291A calibration with the High Impedance Test Head. (Refer to 4291A RF Impedance/Material Analyzer User's Guide .) - Page 23 This information is subject to change without notice. © Keysight Technologies 1994, 1999, 2000, 2015 February 2015 *16453-90010* 16453-90010 www.keysight.com...
