Ingestion: In general, no treatment is neces-
ƒ
sary. If larger amounts have been swallowed,
consult a doctor.
2

Product description and function

2.1

Description

Submersible pump for stationary and portable wet well in-
stallation in intermittent operation.
6
5
4
Fig. 1: Overview
1 Handle
2 Motor housing
Installation and operating instructions Wilo-Rexa MINI3
3
4
5
6
Rexa MINI3-V ... -P
Sewage pump with vortex impeller and vertical threaded
connection. Hydraulics housing made of grey cast iron, im-
peller made of plastic. Surface-cooled 1~ motor with integ-
rated operating capacitor and self-switching thermal motor
monitoring. Stainless steel motor housing. Oil-filled sealing
chamber with double sealing: a rotary shaft seal is installed
on the motor side, a mechanical seal on the pump side. De-
1
tachable connection cable with fitted shockproof plug.
Rexa MINI3-V ... -A
2
Sewage pump with vortex impeller and vertical threaded
connection. Hydraulics housing made of grey cast iron, im-
3
peller made of plastic. Surface-cooled 1~ motor with integ-
rated operating capacitor and self-switching thermal motor
monitoring. Stainless steel motor housing. Oil-filled sealing
chamber with double sealing: a rotary shaft seal is installed
on the motor side, a mechanical seal on the pump side. De-
tachable connection cable with float switch and fitted
shockproof plug.
Discharge connection
Pump housing
Float switch
Connection cable
en
11
