Pioneering for You
Wilo-DrainLift MINI3-XXS
en
User manual
6097573 • Ed.01/2024-04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DrainLift MINI3-XXS and is the answer not in the manual?

Questions and answers

Related Manuals for Wilo DrainLift MINI3-XXS

Summary of Contents for Wilo DrainLift MINI3-XXS

  • Page 1 Pioneering for You Wilo-DrainLift MINI3-XXS User manual 6097573 • Ed.01/2024-04...
  • Page 2 DrainLift MINI3 https://qr.wilo.com/458...

  • Page 3: Table Of Contents

    Removal ............ 13 Maintenance and repair........ 13 Cleaning the lifting unit...... 13 Exchanging the active carbon filter .. 14 Faults.............. 14 10 Information on the collection of used elec- trical and electronic products .......  14 User manual • Wilo-DrainLift MINI3-XXS • Ed.01/2024-04...

  • Page 4: Safety

    • Damage to property: Safety instructions start with a signal word and are displayed without a symbol. Signal words • DANGER! Failure to follow the instructions will result in serious injuries or death! User manual • Wilo-DrainLift MINI3-XXS • Ed.01/2024-04...

  • Page 5: Personnel Qualifications

    Hazardous germs form in sewage. There is a danger of bacterial infec- tions! • All connections must be tight. • Wipe up drips immediately. • Fluids may flow into the room in the event of an accident. User manual • Wilo-DrainLift MINI3-XXS • Ed.01/2024-04...

  • Page 6: Personal Protective Equipment

    Personal protective equipment The aforementioned branded products constitute non-binding sug- gestions. Similar products from other brands can also be used. WILO SE does not assume any liability for the aforementioned products. • Safety gloves (EN 388): uvex phynomic wet • Safety glasses (EN 166): uvex skyguard NT...

  • Page 7: Removal

    For installation in rooms or as a concealed-wall installation. • For backflow resistant drainage of – Drainage points below the backflow level – Drainage points that cannot be drained via the natural downward slope. User manual • Wilo-DrainLift MINI3-XXS • Ed.01/2024-04...

  • Page 8: Improper Use

    Do not connect the following drainage fixtures: • Bathroom/toilet • Dishwasher • Washing machine Intended use also includes compliance with this manual. Any other use is regarded as non-compliant with in- tended use. User manual • Wilo-DrainLift MINI3-XXS • Ed.01/2024-04...

  • Page 9: Product Description

    3 to 40 °C (37 to 104 °F) Operating mode S3 10% Electrical data Mains connection 1~230 V, 50 Hz Power consumption [P 250 W (0.33 hp) Rated power [P 150 W (0.20 hp) Rated current [I 1.2 A Speed [n] 2800 rpm Activation type Direct User manual • Wilo-DrainLift MINI3-XXS • Ed.01/2024-04...

  • Page 10: Scope Of Delivery

    Protect the lifting unit and plug from high water (submersion). • All connections must be tight. • Protect against direct exposure to sunlight. Extreme heat can cause damage to the plastic parts! NOTICE! Keep the original packaging to ensure proper storage. User manual • Wilo-DrainLift MINI3-XXS • Ed.01/2024-04...

  • Page 11: Installation

    Further information and documentation All further information and documentation can be found at the following web address: https://qr.wilo.com/458 • Lifting unit assembly instructions Article number: 6097576 (included in the scope of delivery!) User manual • Wilo-DrainLift MINI3-XXS • Ed.01/2024-04...

  • Page 12: Symbols Used In The Assembly Instructions

    Run clean water into the tank through every connected inlet. ⇒ As soon as the maximum fill level is reached in the tank, the lifting unit switches on. Check all pipe connections for impermeability. Repeat the drainage procedure. User manual • Wilo-DrainLift MINI3-XXS • Ed.01/2024-04...

  • Page 13: More Than Three Months Of Downtime

    Store the lifting unit or dispose of it in accordance with regulations. Maintenance and repair Cleaning the lifting unit • Clean housing with a damp cotton cloth. • Only use household cleaners. • Do not use the following cleaners: User manual • Wilo-DrainLift MINI3-XXS • Ed.01/2024-04...

  • Page 14: Exchanging The Active Carbon Filter

    Observe the locally applicable regulations! Please consult your local municipality, the nearest waste disposal site, or the dealer who sold the product to you for information on proper disposal. See www.wilo‑recycling.com for more information about recycling. User manual • Wilo-DrainLift MINI3-XXS • Ed.01/2024-04...
  • Page 16 Local contact at www.wilo.com/contact WILO SE Wilopark 1 44263 Dortmund Germany T +49 (0)231 4102-0 T +49 (0)231 4102-7363 wilo@wilo.com Pioneering for You www.wilo.com...
