RECOMMENDED TORQUE SETTINGS FOR YOUR SCOTT BIKE

All bolted connections of the bike components have to be tightened carefully
and checked regularly to ensure the safe and reliable operation of the SCOTT
bike. This is best done with a torque wrench that disengages as soon as the
desired torque value has been reached or a click-type torque wrench. Tighten
carefully by approaching the prescribed maximum torque value in small steps
(0.5 Nm increments) and check in between the proper fit of the component.
Never exceed the maximum torque value indicated by the manufacturer!
Where no maximum torque setting is given start with 2 Nm. Observe the indi-
cated values and observe the values on the components and/or in the manuals
of the component manufacturers.
Component
Rear
derailleur
Front
derailleur
Shifter
Brake
lever unit
Hub
Internal
gear hub
Crank
| 112 ENGLISH
Bolted connections
Mount
(on frame/derailleur hanger)
Cable clamp
Pulley wheels
Mount on frame
Cable clamp
Mount on handlebars
Hole covering
Flatbar
Mount on handlebars
Time trial brake lever
Flatbar
Quick-release lever
Lock nut for bearing adjustment
of quick-release hubs
Sprocket cluster lock ring
Hub axle nut
Crank mount
(grease-free square-head)
Crank mount
(Shimano Octalink)
Crank mount
(Shimano Hollowtech II)
Crank mount (Isis)
Crank mount (Giga X Pipe)
Splined
Ultra Torque
Chainring mount
Shimano SRAM/Avid
1
(Nm) (Nm)
8 - 10 8 - 12
5 - 7 4 - 5
3 - 4
5 - 7 3 - 7
5 - 7 5 - 7
5 2 - 5.5
0.3 - 0.5
4 - 8 3 - 5.5
5 - 7.5
10 - 25
29 - 49 40
30 - 45
35 - 50
35 - 50
12 - 14
31 - 34
48 - 54
8 - 11 12 - 14 (steel)
8 - 9 (alu)
Tektro TRP Campagnolo
2 3 4
(Nm) (Nm) (Nm)
2.7
5 - 7
6 - 8
5 - 7
40
(11-speed)
(10-speed)
32 - 38
42 - 60
