- Page 1 2 0 2 3 S C O T T S C A L E M A N U A L 2023 SCALE | ENGLISH 1 |...
-
Page 2: Table Of Contents
SCALE CONTENT THE SCALE SHOULD BE ADJUSTED EXACTLY TO THE RIDER FOR MAXIMUM SAFETY AND RIDEABILITY. Please contact your authorized SCOTT dealer for advice in order to avoid technical problems or any harm. GEOMETRY & TECHNICAL DATA HEADSET ADJUSTMENT RIDELOC... -
Page 3: Geometry & Technical Data
SCALE GEOMETRY & TECHNICAL DATA SEATPOST 31.6 (use carbon grease) SEATPOST CLAMP 34.9 TRAVEL 100 Ft SHOCK LENGTH MAX ROTOR 180 Rr/Ft (160 Rr Small) MAX CHAINRING Tooth 38 MAX TYRE WIDTH CHAINLINE Alloy/Carbon Alloy/Carbon Alloy/Carbon Alloy/Carbon Alloy MY23 SCALE Head tube angle °... - Page 4 SCALE SCALE GEOMETRY & TECHNICAL DATA CONT. The rear brake calliper is a post mounted 160mm If you wish to use two piston brake callipers, you without an adapter. must check the clearance, as not all two piston The maximum rotor size is 180mm, except on brakes will fit.
-
Page 5: Headset Adjustment
SCALE SCALE HEADSET ADJUSTMENT It is important to install the headset correctly depending on the set up required. There are two types of headset cups. 0° & 0.6° ( 64° & 65°) These can be indentified from the stamp on the inner surface of the headset cup The headset is available in two options: 288251 SYN HEADSET ZS56/28.6-ZS56/40 MTB... -
Page 6: Rideloc
SCALE SCALE RIDELOC SCALE RC FORK PART NO. DROPPER SCALE RC SL 3P/0-7-14MM 296245 SCALE RC WORLD CUP EVO 3P/0-7-14MM 296245 SCALE WORLD CUP 3P/0-7-14MM 296245 SCALE RC TEAM ISSUE 2P/0-10MM 296245 SCALE RC TEAM 2P/0-10MM 296245 SCALE FORK PART NO. -
Page 7: Cable Routing
SCALE SCALE CABLE ROUTING For the alloy frames there will be a protective rubber sleeve inside the headtube for the cables. Make sure both the brake and gear cables 297134 SCO CABLE GUIDE H-TUBE INNER SCALE AL 23 can move freely. Foam tubing: 277026 SCO CABLE ANTI-RATTLE LINER 90CM 20 Both cables must route above the bottom bracket. -
Page 8: Spare Parts
SCALE SCALE SPARE PARTS 297086 SCO STEM ACCESSORY COVER COMBO 22 420004 SCO SCALE CARBON 23 CHAINSTAY PROTECTOR 420003 SCO SCALE ALLOY 23 CHAINSTAY PROTECTOR 297132 SCO CHAINGUIDE SCALE CARBON 23 296609 SCO AXLE RWS REAR 148X12 GENIUS PLUG 23 10 Nm 297728 SCO HEADSET KIT SCALE ALLOY 23 2023 SCALE | ENGLISH 8 |... - Page 9 SCALE SCALE SPARE PARTS CONT. 290059 SCO STEM SPACER/TOP CAP SY MTB XC 22 290057 SCO STEM SPACER/TOP CAP SY MTB COMBO 22 290057 SCO STEM SPACER/TOP CAP SY MTB DC 22 290056 SCO HEADSET SPACER KIT IC MTB 22 286000 SCO DROPOUT SRAM UDH 21 297671 SCO DROPOUT SHIMANO UDH DM 23 Reverse Thread...
-
Page 10: Manufacture's Guarantee
SCOTT, the duration of the manufacturer’s guarantee is limited to two years. If a defect on the SCOTT bicycle is remedied within the scope of a manufacturer’s guarantee or a warranty claim, the duration of the manufacturer’s guarantee is not extended. The manufacturer’s guarantee ends, when the first-time buyer transfers ownership of the SCOTT bicycle to a third person. - Page 11 English version will be relevant in case of conflict. P.E.D Zone C1, Rue Du Kiell 60 | 6790 Aubange | BelgiumDistribution: SSG (Europe) Distribution Center SA SCOTT Sports SA | 11 Route du Crochet | 1762 Givisiez | 2022 SCOTT Sports SA www.scott-sports.com Email: webmaster.marketing@scott-sports.com...
