  • Page 1 Moon Hi-Fi Bavaria AXIAL FAN USER’S MANUAL...
  • Page 2: Table Of Contents

    CONTENTS Delivery set ................................................6 Brief description ..............................................6 Operation guidelines ............................................6 Designation key ..............................................7 Mounting ................................................. 7 Electronic system operation algorithm ....................................7 Maintenance................................................9 Storage and transportation regulations ....................................9 Manufacturer’s warranty ..........................................10...
  • Page 3 BLAUBERG VENTILATOREN GmbH is happy to offer you a new generation products, the BLAUBERG Moon, Hi-Fi and Bavaria fans. The solid team of high-qualified professionals with many years of working experience, technological innovations in design and production, high-quality components and materials from the top worldwide producers have become the precondition for the best fans in theirs class.
  • Page 4 FOLLOW THE USER’S MANUAL REQUIREMENTS TO ENSURE DURABLE AND TROUBLE-FREE OPERATION OF THE UNIT. Disconnect the unit from power supply prior to any connection, servicing, maintenance, and repair operations. Only qualified electricians with a work permit for electrical units up to 1000 V are allowed for installation and maintenance.
  • Page 5 equipment to prevent back drafting. Transported air must not contain any dust or other solid impurities, sticky substances, or fibrous materials. • Do not use the unit in a hazardous or explosive environment containing spirits, gasoline, insecticides, etc. • Do not close or block the intake or extract vents in order to ensure the efficient air flow. •...
  • Page 6: Delivery Set

    DELIVERY SET - 1 pc. Screws with dowels - 4 pcs. Plastic screwdriver - 1 pc. (only for the models with a timer) User’s manual - 1 pc. Packing box - 1 pc. BRIEF DESCRIPTION The product is an axial fan for exhaust ventilation of small and medium-sized premises heated in winter. The design of the fan may include a back valve that prevents air from flowing into the room when the fan is off.
  • Page 7: Designation Key

    DESIGNATION KEY Blauberg Moon Extra options _ — basic model S — cord-operated switch Т — deactivation and activation delay timer Н — humidity sensor and deactivation delay timer Outlet duct diameter [mm] _ — single-speed motor V2 — double-speed motor...
  • Page 8: Electronic System Operation Algorithm

    ELECTRONIC SYSTEM OPERATION ALGORITHM A fan with a T timer — when the control voltage is applied to the S input by an external switch (for example, switching on the room light), the turn-on delay timer is activated, and the fan blades do not rotate. The value of the turn-on delay time is adjustable in two ranges - from 0 to 2 minutes.
  • Page 9: Maintenance

    — To adjust the fan activation delay time, turn the T potentiometer knob clockwise (+) or counter-clockwise (-) which sets the activation delay time within the range from 0 to 2 minutes. — To adjust the fan deactivation delay time, turn the T potentiometer knob clockwise (+) or counter-clockwise (-) which sets the activation delay time within the range from 2 to 30 minutes.
  • Page 10: Storage And Transportation Regulations

    TROUBLESHOOTING Problem Possible reasons Troubleshooting Make sure the power supply line When the unit is connected to power No power supply. is connected correctly, otherwise troubleshoot the connection error. mains, the fan does not rotate and does not respond to any controls. Internal connection fault.
  • Page 11: Manufacturer's Warranty

    MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Council Directive 2014/30/EU, Low Voltage Directive 2014/35/EU and CE-marking Directive 93/68/EEC. This certificate is issued following test carried out on samples of the product referred to above.
  • Page 12 • Replacement and use of any assemblies, parts and components not approved by the manufacturer. • Unit misuse. • Violation of the unit installation regulations by the user. • Violation of the unit control regulations by the user. • Unit connection to power mains with a voltage different from the one stated in the user's manual. •...
  • Page 13 ø 99...
  • Page 15 Blauberg Moon 100 T Blauberg Moon 100 ST Fan does not run Contact of the S1 switch or the pull cord switch is CLOSED Fan runs Contact of the S1 switch or the pull cord switch is OPENED Activation of turn-off...
  • Page 16 Blauberg Moon 100 H Blauberg Moon 100 SH Fan does not run Contact of the S1 switch or the pull cord switch is CLOSED Humidity exceeds set point Fan runs Contact of the S1 switch or the pull cord switch is...
  • Page 17 Blauberg Moon V2 100 T Blauberg Moon V2 100 ST Fan runs at speed 1 Contact of the S1 switch or the pull cord switch is CLOSED Activation of turn-on delay timer (0-2 minutes) Fan runs at speed 2 Contact of the S1 switch...
  • Page 18 Blauberg Moon V2 100 H Blauberg Moon V2 100 SH Fan runs at speed 1 Contact of the S1 switch or the pull cord switch is CLOSED Humidity exceeds set point Activation of turn-on delay timer (45 seconds) The contact of the S1 switch...
  • Page 19 Blauberg Moon V2 100 Blauberg Moon V2 100 S speed 1 and 2 Fan does not run Contact of the S1 switch or the pull cord switch is CLOSED S switch is in Speed position Fan runs at speed 1...
  • Page 23 Quality Inspector’s Stamp Seller (name and stamp of the seller) Manufacture Date Purchase Date...
  • Page 24 Moon Blauberg Hi-Fi Bavaria www.ventilation-system.com B160EN-04...
