TC-734-IP

Rev. A, June 2018

www.commscope.com

Content

FIST-GR2-SMS

(Splicing Machine Support)

1 Introduction

2 Mounting possibilities

3 Maximum load

1 Introduction

The FIST-GR2-SMS-01 is a Splicing Machine Support to facilitate splicing in an optical distribution frame and

allows bringing the splicing machine closer to the splicing shelf. It can be mounted on the front side of shelves,

already installed in the rack or on the rack mounting uprights (back or front mounting).

Features

•

Attachment brackets and wing nuts are secured to the support.

•

The support can be used with:

•

Safety locks are foreseen in the slots of the support to avoid accidental moving of the securing system.

FIST Racks & Shelves

I N S T A L L A T I O N

4 Mounting the splicing machine

support

4.1 Rack Mounting

4.2 Shelf mounting

- 19" and ETSI uprights (back- or front mounted)

- 19" and ETSI shelves.

I N S T R U C T I O N

Need help?

Do you have a question about the FIST-GR2-SMS-01 and is the answer not in the manual?

Page 1 4.2 Shelf mounting 1 Introduction The FIST-GR2-SMS-01 is a Splicing Machine Support to facilitate splicing in an optical distribution frame and allows bringing the splicing machine closer to the splicing shelf. It can be mounted on the front side of shelves, already installed in the rack or on the rack mounting uprights (back or front mounting).
Page 2 Mounting possibilities...
Page 3 Maximum load 4.1.4 Place the splicing unit and necessary tools onto the support (Max. 25 Kg ) and prepare the to be spliced shelve according to the The maximum load is 25 Kg. appropriate instruction. Mounting the splicing machine support Shelf mounting Rack mounting 4.2.1...
