General
®
The iPatch
600A shelf with faceplate is a SYSTIMAX
connection of non-metallic Outside Plant (OSP) cable or Lightguide Building Cable (LGBC) to 12 iPatch SC
duplex fiber ports or 24 iPatch LC duplex fiber ports either by direct termination or splicing. Designed for use in
an iPatch system, this shelf is one unit high and can be mounted in a standard 19-inch rack with a universal hole
pattern.
Note: To use the iPatch 600A shelf in an existing iPatch system, the network manager and rack managers
must be running software version 6.03 or later. The System Manager software, used to manage the system,
must be Version 6.2 or later. We recommend that you upgrade the System Manager software to Version 6.2 or a
later version before you install the shelf. System Manager will automatically upgrade the iPatch Manager
software.
Ordering information is listed below:
Material ID
760005595
iP-600A-12-SC-MMF
760080887
iP-600A-12-CSC-SMF
How to Contact Us
To find out more about CommScope
For technical assistance:
-
Within the United States, contact your local account representative or technical support at
1-800-344-0223. Outside the United States, contact your local account representative or Authorized
Business Partner.
-
Within the United States, report any missing/damaged parts or any other issues to
CommScope Customer Claims at 1-866-539-2795. Outside the United States, contact your
local account representative or Authorized Business Partner.
This product is covered by one or more of the following U.S. patents or their foreign equivalents: 6,285,293 and 6,522,737.
www.commscope.com
®
iPatch
600A Shelf with Faceplate Instructions
Part No.
600A fixed multimode intelligent fiber shelf, SC 12 port duplex
600A fixed SC single-mode intelligent fiber shelf, 12 port duplex ceramic
®
products, visit us on the web at
© 2012 CommScope, Inc. All rights reserved
®
approved product. This distribution shelf provides for
Description
http://www.commscope.com/
For RoHS Inquiries:
CommScope Inc.
Corke Abbey, Bray
Co. Dublin, Ireland
Attn: Legal Department
Instruction Sheet 860106368
Issue 6, December 2012
Page 1 of 12
