Two rack unit fiber management tray
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ADCP-90-459
Issue 2, June 2016
Content
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
1
PRODUCT INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1.1
1.2
1.3
2
DIMENSIONS AND SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
3
UNPACKING THE PRODUCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4
MOUNTING THE 2RU FMT ON THE RACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5
INSTALLING MICRO-VAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
300001717914 Rev B
www.commscope.com
Two Rack Unit (2RU)
Fiber Management Tray (FMT)
2RU FMT (Micro-VAM Configuration Shown)
General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Configurations and Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1.2.1
Termination (Universal Entry) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2.2
Termination (Left Entry for IFC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2.3
Micro-VAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2.4
48-Position Termination/Splice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.2.5
Bulk Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Attenuators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Instruction Sheet
© 2016 CommScope. All Rights Reserved.
FMT
24290-A
Page
(continued)
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2RU FMT and is the answer not in the manual?

Questions and answers

Related Manuals for CommScope 2RU FMT

Summary of Contents for CommScope 2RU FMT

  • Page 1: Table Of Contents

    MOUNTING THE 2RU FMT ON THE RACK ........

  • Page 2: Introduction

    REASON FOR CHANGE 3/2011 Original Trademark Information CommScope (logo), CommScope, and ADC are trademarks, Scotchlok are registered trademarks of 3M Company. FiberLok is a trademark of 3M Company. VELCRO is a registered trademark of Velcro Industries, B.V. Admonishments Important safety admonishments are used throughout this manual to warn of possible hazards to persons or equipment.

  • Page 3: Product Introduction

    (DIP) installed inside the drawer to provide various functions such as cable termination. The basic chassis is the same for all models of the 2RU FMT. The drop-in plate, which is installed in the factory, depends on customer order.

  • Page 4: Configurations And Components

    Figure 1. 2RU FMT (Micro-VAM Model Shown) Configurations and Components The 2RU FMT is currently available in a variety of DIP configurations, with more being developed based on customer requests. The configurations available as of this printing of this manual are: •...
  • Page 5 (2 PLACES) (2 PLACES) LOCK OPEN LATCH 24300-A SLIDE LATCH MOUNTING (2 PLACES) BRACKET (2 PLACES) SLIDING RADIUS LIMITER (2 PLACES) KEYLOCK (OPTIONAL) Figure 2. 64-Position Termination Only (Universal Entry) 2RU FMT Page 5 © 2016 CommScope. All Rights Reserved.

  • Page 6: Termination (Left Entry For Ifc)

    • Dual circuit micro-VAMs have two input ports and four output ports. 2RU FMT capacity is 12 inputs and 24 outputs for a tray loaded with single-circuit micro- VAMs, and 24 inputs and 48 outputs for a tray loaded with dual circuit micro-VAMs.

  • Page 7: 48-Position Termination/Splice

    MOUNTING LATCH BRACKET (2 PLACES) (2 PLACES) SLIDING RADIUS LIMITER (2 PLACES) KEYLOCK (OPTIONAL) Figure 4. 64-Position Micro-VAM 2RU FMT 1 x N SPLITTER 1 x N SPLITTER 18643-A Figure 5. Sliding Micro-VAM With Dual-Circuit Schematic Label 1.2.4 48-Position Termination/Splice Figure 6 shows the 48-Position Termination/Splice model.
  • Page 8 SPLICE LIMITERS RADIUS TRAY LIMITER (2 PLACES) 24294-A SLIDE LATCH (2 PLACES) MOUNTING BRACKET SLIDING RADIUS (2 PLACES) LIMITER (2 PLACES) SLIDING KEYLOCK ADAPTER (OPTIONAL) 6-PACKS Figure 6. 48-Position Termination/Splice 2RU FMT Page 8 © 2016 CommScope. All Rights Reserved.

  • Page 9: Bulk Storage

    (back) side of sliding adapter packs. 2 DIMENSIONS AND SPECIFICATIONS Figure 8 shows 2RU FMT dimensions for rack type, rack width, and recess options. Table 1 lists specifications for the 2RU FMT.
  • Page 10 ETSI 20.28 IN. 51.5 CM WECO 1.0 IN. 2.5 CM 19-INCH EIA/WECO 18.31 IN. 46.5 CM 1.25 IN 3.25 CM 23-INCH EIA/WECO 22.32 IN 56.7 CM 18547-B Figure 8. 2RU FMT Dimensions Page 10 © 2016 CommScope. All Rights Reserved.

  • Page 11: Unpacking The Product

    1. Inspect the exterior of the shipping container for evidence of rough handling that may have damaged the contents of the container. 2. Unpack the 2RU FMT and check for possible damage. 3. If damage is detected or if parts are missing, file a claim with the commercial carrier and then notify ADC Customer Service.

  • Page 12: Mounting The 2Ru Fmt On The Rack

    ADCP-90-459 • Issue 2 • June 2016 4 MOUNTING THE 2RU FMT ON THE RACK For all mounting configurations, the 2RU FMT uses two mounting brackets, one on either side. Each bracket has four mounting holes (see Figure 9), but only the top and bottom holes are required.
  • Page 13 ADCP-90-459 • Issue 2 • June 2016 18612-A GUIDE REAR RADIUS LIMITER Figure 10. Installing a Micro-VAM Page 13 © 2016 CommScope. All Rights Reserved.

  • Page 14: Installing And Routing Cables

    Route only jacketed fibers through the sliding radius limiters. CABLE CLAMP SUBUNIT BREAKOUT POINT FOR 6, 12, OR 24 FIBER SUBUNIT OR INDIVIDUAL JACKET OR 2 MM CABLES 24295-A FRAME SLIDING RADIUS LIMITER Figure 11. Cable Clamping Point Page 14 © 2016 CommScope. All Rights Reserved.

  • Page 15: Internal Cable Routing

    1. Open tray fully and lock it using the lock open latch (see Subsection 7.1 Opening the Tray). 2. Route the cable along the rack to the 2RU FMT, as shown in Figure Note: The cable may be routed from either above or below the tray. It may be routed into the 2RU FMT from either the left or right side.
  • Page 16 Note: Always clean and inspect connectors and adapters before mating them. For guidelines, refer to the connector cleaning instructions, ADCP-90-159. 6. Secure the cables on the side and rear of the tray as shown in Figure Page 16 © 2016 CommScope. All Rights Reserved.

  • Page 17: Termination (Left Entry For Ifc)

    Subsection 7.1 Opening the Tray). 2. Route the cable along the rack to the 2RU FMT, as shown in Figure 11 on page Note: The cable may be routed from either above or below the tray on the left side.
  • Page 18 Note: Always clean and inspect connectors and adapters before mating them. For guidelines, refer to the connector cleaning instructions, ADCP-90-159. 6. Secure the cables on the side and rear of the tray as shown in Figure Page 18 © 2016 CommScope. All Rights Reserved.

  • Page 19: Micro-Vam

    3. Secure the cable to the rack using local practice. 4. Route the cable into the fully-open tray through the cable guide as shown. Page 19 © 2016 CommScope. All Rights Reserved.
  • Page 20 A protective cap or hood MUST be immediately placed over any radiating adapter or optical fiber connector to avoid the potential of dangerous amounts of radiation exposure. This practice also prevents dirt particles from entering the adapter or connector. Page 20 © 2016 CommScope. All Rights Reserved.

  • Page 21: 48-Position Termination/Splice

    Cables routed into the tray for splicing or termination are normally multifiber cable assemblies. Cables to be spliced will be bare-ended. Cables to be terminated will be pre-terminated. The 2RU FMT will also have factory-installed, internal pigtails between splice tray and connector bulkhead. Refer to the following instructions.
  • Page 22 1. Open the tray fully and lock it using the lock open latch (see Subsection 7.1 Opening the Tray). 2. Route cables along the rack to the 2RU FMT, as shown in Figure 19. Route cable to be spliced on the left side of the rack. Route cable to be terminated on the right side of the rack.
  • Page 23 8. To connect an individual cable connector to an adapter, lift up the release tab on top of the adapter pack and slide up the adapter pack (see Figure 25 on page 28). Pull the dust cap straight out from the adapter and connect the cable connector to the adapter. Page 23 © 2016 CommScope. All Rights Reserved.

  • Page 24: Bulk Storage

    1. Open the tray fully and lock it using the lock open latch (see Subsection 7.1 Opening the Tray). 2. Route the patch cords along the rack to the 2RU FMT, as shown in Figure 22. Route the patch cords in from either side of the tray.
  • Page 25 4. Route the patch cords into the fully-open tray through the cable guides as shown. Note: The sliding radius limiters must be in the position shown. 5. Route the patch cords within the tray as shown in Figure Page 25 © 2016 CommScope. All Rights Reserved.

  • Page 26: Operation

    Note: For maximum storage, balance the load between the two sides. 7 OPERATION Operation consists of opening the tray, connecting patch cords to adapters or micro-VAMs, and closing the tray. When routing patch cords, refer to the routing diagrams provided in Section Page 26 © 2016 CommScope. All Rights Reserved.

  • Page 27: Opening The Tray

    Opening the Tray To open the 2RU FMT tray, slide the release tabs inward with both hands and pull the drawer straight out as far as it goes. While working in the tray, lock tray in position as shown in Figure 24.

  • Page 28: Micro-Vams

    ADCP-90-159. 3. Pull the dust cap straight out. 4. Connect the patch cord connector to the desired adaptor. 5. Close the tray as described in Subsection 7.4 Closing the Tray. Page 28 © 2016 CommScope. All Rights Reserved.

  • Page 29: Closing The Tray

    4. Slowly close the tray, observing that no fiber kinks or macro bends occur as a result of fiber routing. 5. Latch tray shut using the lock open latch (“locked position” shown in Figure 24 on page 27). Page 29 © 2016 CommScope. All Rights Reserved.

  • Page 30: Technical Assistance

    ADCP-90-459 • Issue 2 • June 2016 8 TECHNICAL ASSISTANCE Contact the Technical Assistance Center (TAC) for technical question. Call 800.830.5056 or send an email to TAC.Americas@commscope.com. Page 30 © 2016 CommScope. All Rights Reserved.
