CommScope BSAMNT Series Installation Instructions

Mounting Kits For Wide Panel Antennas
BSAMNT Series: Mounting systems for
installations (60-115mm pipe diameter) for heavy duty applications
Bulletin 639834 • Revision A • December 2014 • Page 1 of 2
ITEM NO.
two hole plate
MAXIMUM TORQUE
M8 15N.m (11ft.lbs)
M10 37N.m (27ft.lbs)
M12 58N.m (43ft.lbs)
ATTENTION: Insert M12 bolts and M12
flat washers into bracket with tabs
prior to attaching bracket to antenna.
cylindrical pipe
DESCRIPTION
1 PIPECLAMP BRACKET, NO FLANGE
2 PIPECLAMP BRACKET, SHORT FLANGES
3 NOTCHED BRACKET
4 BRACKET
5 SCR,HH,HEX,M8X25,SST,PASS
6 WSHR,LK,SPLT,M8,STL,GALV
7 TWO HOLE PLATE, 8mm X 1.25 PITCH
8 NUT,HEX,M10,STL,GALV
9 WSHR,LK,SPLT,M10,STL,GALV
10 SCR,HCS,HEX,M10X40,STL,GALV
11 NUT,HEX,M12,STL,GALV
12 WSHR,FLT,M12,13X28X2.5,STL,GALV
13 WSHR,LK,SPLT,M12,STL,GALV
14 BOLT,CARRIAGE,M12 X 200,STL,GALV
7
5
M8 bolt

Pre-assembly of Downtilt Brackets

M10 bolt
8 9
12
13
11
1

Middle Mount Installation

Installation Instructions

CommScope Infrastructure Academy offers installation training.
QTY
1
1
1
1
4
4
2
8
4
4
4
2
2
2
Part Lists
6
• Bracket edges parallel to each other.
(fully collapsed position)
M10 bolt
8 9 10
M12 bolt
14
2
U/M
EA
EA
EA
EA
EA
EA
EA
EA
EA
EA
EA
EA
EA
EA
3
4
CRITICAL: For initial installation
to pipe, downtilt brackets must
be configured in pre-assembly
position (fully collapsed).
