CommScope OTE-M Installation Instructions

TC-1360-IP
Rev. A, July 2017
www.commscope.com
OTE-M Pole-Mount Bracket Kit
Table of Contents
1 General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Kit Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3 Installing an OTE-M Pole-Mount Bracket Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
4 Product Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1 General
The OTE-M Pole-Mount Bracket Kit is a unique solution designed for mounting CommScope's Mini-OTE
300 in applications that require the product to be secured to a pole. See
MOUNTING HOLES
MOUNTING BRACKET
CABLE TIE SLOT
3/8" SELF-TAPPING SCREW
660001189
Rev A
R R A A
Installation Instructions
MINI-OTE 300 TERMINAL ENCLOSURE
MOUNTING HOLES
CABLE TIE SLOT
MOUNTING BRACKET
3/8" SELF-TAPPING SCREW
Figure 1. OTE-M Pole-Mount Bracket Kit
© 2017 CommScope, Inc. This product is covered by one or more U.S.
patents or their foreign equivalents. For patents, see
All rights reserved
www.commscope.com/ProductPatent/ProductPatent.aspx
Figure 1.
CABLE TIE
1
