2.
1) Bowl disassembly [AMD20]
Step 1
Remove the bowl assembly from the product.
If the bowl assembly is tightened too much to be removed, use a hook spanner until it can be loosened by
hand.
2.2) Bowl assembly [AMD20]
Step 2
Screw the bowl assembly into the product.
Tighten it referring to the specified torque below.
Screw fitting
Body
Joint
④ Bowl Assembly
Body
④ Bowl Assembly
Tightening
Recommended tightening torque:
2.2N・m
-25-
Rotation
