T H E P O L A R I S S H A D E M A K E R S I D E P O S T D E S I G N
The Polaris sidepost umbrella has an elegant and noble design, combined with a
robust construction and easy to handle. The unique fitting function makes the
perfect shade for the home or in the restaurant.
D I A G R A M & L E G E N D
8
9
7
6
5
4
3
2
1
1. Internal Stem
2. Acetal Ring
3. Turning Handle
4. Mast
5. Slider Car Stop Pin
6. Crank
7. Slider Car
8. Upper End Fitting
3
12
10
11
13
20
17
18
19
9. Main Support Arm
10. Large Arm End Fitting
11. Large Hinge
12. Main Arm
13. Upper Hub
14. Small Hinge
15. Main Canopy Arm
16. Small Arm End Fitting
14
15
16
21
17. Strut
18. Lower Hub
19. Light Adapter
20. Center Tube
21. Canopy
