To install DIMMs in the Security Management Appliance:
1. Find the DIMM slots on the system board.
The basic memory configuration of the Security Management Appliance
ships with these DIMMs installed:
• Smart-1 205: 2
• Smart-1 210: 2
•
Smart-1 225: 2
• Smart-1 3050: 8
•
Smart-1 3150: 8
2. Press on the two white retaining clips outward.
3. Align the new DIMM above the socket.
The top of the DIMM is smooth. The bottom edge has two different-length
sets of contacts, which connect to the slots on the socket.
Important:
• Only touch the top corners of the DIMM. Pressing on the heat sink or
other DIMM components can damage the hardware.
