Page 12
3
EMERGENCY INTERCOMMUNICATION (WIP)
OPERATION
The Emergency Intercommunication System provides telephone style communication
from the master warden intercommunication phone (WIP) on the master panel to
remote telephone type WIP handsets located remotely in the evacuation zones.
The operation of the WIP system is entirely independent of the Emergency Warning
System and is not affected by the operation of the AUTO/MANUAL/ISOLATE
keyswitch.
3.1
WIP CONTROL LED / SWITCH MODULE
Figure 6 shows the LED/SWITCH WIP modules controlling the following functions:
SELECTIVE ZONE WIP OPERATION
SELECTIVE ZONE MANNED/CLEARED OPERATION
Figure 6
Document No.: 4100-M010A
WIP Control LED / Switch Panel
May 1999
SIMPLEX 4100 EWIS
OPERATOR MANUAL
Issue 3.1
