START-UP
25-50 Tons
YORK
Sun
Premier Rooftop Units
®
™
R-410A
Nomenclature ...................................................................... 4
Pre Start-Up Checklist ......................................................... 7
Start-Up ............................................................................... 9
Long Term Storage ......................................................... 9
Unit Checks (Power Applied) ....................................... 10
Initial Start-Up .............................................................. 16
Refrigerant Charge ............................................... 16
Checking Sub-Cooling and Superheat.................. 16
Leak Checking ...................................................... 17
Gas Heat Models .................................................. 17
Phase Monitor Adjustment .................................... 20
Commissioning Mode................................................... 20
Air Balancing Wizard .................................................... 20
Start-Up Wizard ............................................................ 24
Start-Up Wizard Sequence ................................... 26
Sequences of Operation .................................................... 30
Control Boards ............................................................. 30
Variable Frequency Drives (VFDs) ............................... 37
Unit Type ...................................................................... 38
Occupancy Mode ......................................................... 38
Morning Warm-up/Cool Down ............................... 38
Coast..................................................................... 38
Remote Safety Shutdown ............................................ 39
Low Voltage Monitoring ................................................ 39
Supply Fan Operation .................................................. 39
Supply Fan Alarm.................................................. 39
MZVAV Supply Fan ............................................... 39
SZVAV Supply Fan ............................................... 40
Redundant Supply Fan VFD ................................. 40
Cooling Operation ........................................................ 40
MZVAV Cooling Operation .................................... 40
SZVAV Cooling Operation ..................................... 42
Compressors and Refrigeration Circuits ............... 42
OPERATION
&
Table of Contents
Compressor Staging Sequences .......................... 44
Condenser Systems and Fans.............................. 48
Dehumidification (Hot Gas Reheat) ...................... 49
Economizer ........................................................... 51
Heating ......................................................................... 52
Gas Heating .......................................................... 52
Electric Heating ..................................................... 56
Hydronic Heating .................................................. 56
MZVAV Heating Operation .................................... 56
SZVAV Heating Operation .................................... 57
Ventilation..................................................................... 58
Ventilation Sequences .......................................... 58
Low Mixed Air Temperature Limiting ..................... 58
Demand Control Ventilation .................................. 58
Continuous Ventilation .......................................... 59
Pre-Occupancy Purge........................................... 59
Humidification............................................................... 60
Humidification Sequence ...................................... 60
Exhaust System ........................................................... 60
Modulating Exhaust Fan ....................................... 60
Modulating Exhaust Damper with Fan .................. 60
External Control .................................................... 60
Return Fan ................................................................... 60
Return Fan Discharge Pressure ........................... 61
Supply Fan Airflow Tracking.................................. 61
Energy Recovery Wheel .............................................. 61
Single Speed Energy Recovery Wheel ................. 61
Variable Speed Energy Recovery Wheel .............. 61
Ultraviolet Lights........................................................... 61
Smoke Control ............................................................. 62
Purge .................................................................... 62
Pressurization ....................................................... 62
Depressurize ......................................................... 62
LD26877
5587001-YSG-A-520
Advertisement
Table of Contents
Related Manuals for York Sun Premier GZA1M Series
Summary of Contents for York Sun Premier GZA1M Series
-
Page 1: Table Of Contents
START-UP OPERATION & 25–50 Tons YORK Premier Rooftop Units ® ™ R-410A LD26877 Table of Contents Nomenclature ..............4 Compressor Staging Sequences ......44 Pre Start-Up Checklist ............7 Condenser Systems and Fans......48 Start-Up ................9 Dehumidification (Hot Gas Reheat) ...... 49 Long Term Storage ............ - Page 2 Table 28: BACnet IP Settings ..............................96 Table 29: BACnet MS/TP Settings .............................. 97 Table 30: MAP Gateway Related Documentation ........................97 Table 31: Verasys Related Documentation ..........................98 Table 32: BACnet Points List ..............................98 Table 33: Faults List .................................. 117 YORK...
