CY14NVSRAMKIT-001

nvSRAM DEVELOPMENT KIT

VCC POWER LED

SK-FM4-U120-9B560

32.768 kHz

(LED1)

compatible header

RTC Crystal

INT/INT1

STATUS LED

(LED2)

Test

Points

RTC Backup

SK-FM4-U120-9B560

16-Mbit nvSRAM,

0.1 Farad Cap

compatible header

with RTC, 165 FBGA

CY14NVSRAMKIT-001 Features:

• 16-Mbit (1Mx16), parallel nvSRAM with RTC

• SK-FM4-U120-9B560 compatible headers

• 3.3 V VCC Power Supply

• VCC POWER (LED1) and INT/INT1 STATUS (LED2) LEDs

• Test points for HSB (HSB#, HSB1#) and RTC (INT, INT1)

• 0.1 Farad super capacitor provides RTC backup for

more than two days

Table of Contents

Do you have a question about the CY14NVSRAMKIT-001 and is the answer not in the manual?

Page 1 SK-FM4-U120-9B560 16-Mbit nvSRAM, 0.1 Farad Cap compatible header with RTC, 165 FBGA CY14NVSRAMKIT-001 Features: • 16-Mbit (1Mx16), parallel nvSRAM with RTC • SK-FM4-U120-9B560 compatible headers • 3.3 V VCC Power Supply • VCC POWER (LED1) and INT/INT1 STATUS (LED2) LEDs •...
Page 2 CY14NVSRAMKIT-001 nvSRAM DEVELOPMENT KIT • This kit is designed for use with Cypress’s FM4 MCU Evaluation Board (SK-FM4-U120-9B560) • Download the kit installer and documentation from www.cypress.com/CY14NVSRAMKIT-001 • Configure the MCU for program. Upon successful programming, configure the MCU for run. Refer to the Kit Operation chapter 4 in CY14NVSRAMKIT-001 User Guide for the MCU configurations •...
