Hardware Description
2.4.7 Push-Buttons and LED Indicators
Table 8 list the push-button definitions. See
Reference
SW1
SW2
SW3
SW4
Table 9 lists the LED indicators. See
Reference
D1, D2
D3
D6
D7
D8
(1)
GPIO_10 and GPIO_11 are also used as I
configuring the GPIOs.
16
CC3235x SimpleLink™ Wi-Fi
CC3235x)
Figure 1
Table 8. Push-Button Definitions
Use
RESET
GPIO_13
GPIO_22
Factory default (FRST)
Figure 1 for location.
Table 9. LED Indicators
Color Use
Green and Red Debug
Yellow nRESET
Red Factory Reset
RGB
GPIO_10
GPIO_11
GPIO_09
Red Power
2
C. Thus, when the pull-up resistors are enabled, the LEDs are on by default, without
®
LaunchPad™ Development Kit (LAUNCHXL-
Copyright © 2019, Texas Instruments Incorporated
for location.
Comments
This signal is used to reset the CC3235 device. This signal is also output
on the 20-pin connector to reset any external BoosterPack that may be
stacked. The reset can be isolated using the jumper block at the center
of the board.
When pushed, GPIO_13 is pulled to VCC.
When pushed, GPIO_22 is pulled to VCC.
Pressing this button and toggling RESET (SW1) restores the factory
default image on the serial flash. This can be used to recover a
corrupted serial flash, provided the s-flash was programmed with a
recovery image.
Comments
Indicates the state of the JTAG emulator. For TI
use only.
Indicates the state of the nRESET pin. If this LED
is on, the device is functional.
Indicates that the push-button for the factory reset
is pressed.
On when the GPIO_xx is logic-1.
(1)
(1)
Indicates when the 3.3-V power is supplied to the
board.
