Hardware Description
2.4.5 Sense on Power (SOP)
The CC3235 device can be set to operate in four different modes, based on the state of the sense-on-
power (SOP) lines. These SOP lines are pins 21, 34, and 35 on the CC3235 device.
states of the device, and
can be be pulled up or pulled down. The bottom of the SOP configuration is pull ups, and top is pull
downs. The current SOP configuration in
14
CC3235x SimpleLink™ Wi-Fi
CC3235x)
Figure 9 shows the SOP jumpers. Each SOP line has a 3 position header that
Figure 9
Table 7. J15, J16, J17 on LaunchPad™
SOP[2:0] (Binary)
000
001
010
011
100
Figure 9. SOP Jumpers (Default Setting Shown)
®
LaunchPad™ Development Kit (LAUNCHXL-
Copyright © 2019, Texas Instruments Incorporated
would then be 010 (Flash/Function).
Function
Functional mode and 4-wire JTAG
Functional mode and 2-wire JTAG
Functional mode and flash programming
Factory default
Flash programming
www.ti.com
Table 7 lists the
