Juniper CTP2000 Series Upgrade
Circuit to packet platform upgrade to ctpos 7.x
Hide thumbs
Also See for CTP2000 Series:
- Hardware documentation (150 pages) ,
- Hardware manual (149 pages) ,
- Quick start manual (27 pages)
Related Manuals for Juniper CTP2000 Series
Summary of Contents for Juniper CTP2000 Series
- Page 1 Juniper Networks CTP2000 Circuit to Packet Platform Upgrade to CTPOS 7.x Modified: 2015-11-17 Copyright © 2015, Juniper Networks, Inc.
- Page 2 Products made or sold by Juniper Networks or components thereof might be covered by one or more of the following patents that are owned by or licensed to Juniper Networks: U.S. Patent Nos. 5,473,599, 5,905,725, 5,909,440, 6,192,051, 6,333,650, 6,359,479, 6,406,312, 6,429,706, 6,459,579, 6,493,347, 6,538,518, 6,538,899, 6,552,918, 6,567,902, 6,578,186, and 6,590,785.
-
Page 3: Table Of Contents
Chapter 2 Upgrading the CTP2000 Series Device to CTPOS 7.x ....11 Upgrading with the PP310 Upgrade Kit ........11 Upgrading with the PP332 Upgrade Kit . - Page 4 Upgrading the CTP2000 Series Device to CTPOS 7.x Copyright © 2015, Juniper Networks, Inc.
- Page 5 Chapter 2 Upgrading the CTP2000 Series Device to CTPOS 7.x ....11 Figure 3: RTM Default Jumper Settings ........12 Figure 4: CompactFlash Adapter with CompactFlash Card Inserted .
- Page 6 Upgrading the CTP2000 Series Device to CTPOS 7.x Copyright © 2015, Juniper Networks, Inc.
-
Page 7: Introduction To Ctpos 7.0 Upgrade Kits
This topic includes the procedures for performing an upgrade using an upgrade kit and for registering the upgrade. There are three upgrade kits, the use of which depends on whether you are using a PP310, PP332, or PP833 processor in your CTP2000 series device. -
Page 8: Pp310 Upgrade Kit - Ctp2000-Ram-Rtm-Upg
NOTE: The use of the upgrade kit is supported only on CTP2000 Series products. CAUTION: You cannot use CTPView to perform a system save of a node running a version of CTPOS before 7.0R1 and restore the system to a node... -
Page 9: Pp833 Upgrade Kit - Ctp2000-Ram-Rtm-Upg
Locator: ChannelB-DIMM0 Bank Locator: BANK 2 Type: DDR3 Type Detail: Synchronous Speed: Unknown Manufacturer: CCT Memory Serial Number: No serial number Asset Tag: 0123456789 Part Number: No part number Rank: Unknown Configured Clock Speed: 1333 Copyright © 2015, Juniper Networks, Inc. - Page 10 Upgrading the CTP2000 Series Device to CTPOS 7.x Copyright © 2015, Juniper Networks, Inc.
-
Page 11: Upgrading The Ctp2000 Series Device To Ctpos 7.X
Remove the RTM from the chassis and remove the old CompactFlash card from the RTM. See “Installing or Removing a CTP2000 Series CompactFlash Card” on page Confirm that the jumper settings on the new RTM provided in the upgrade kit conform... -
Page 12: Figure 3: Rtm Default Jumper Settings
Upgrading the CTP2000 Series Device to CTPOS 7.x Figure 3: RTM Default Jumper Settings Board Compatibility (set to suit processor board) PP310 PP332 Confirm that Ethernet dip switches SW1 and SW2 are set to ON, and that SW3 and SW 4 are set to OFF (see Figure 3 on page 12). -
Page 13: Upgrading With The Pp332 Upgrade Kit
Chapter 2: Upgrading the CTP2000 Series Device to CTPOS 7.x NOTE: The system may go through multiple reboots during this process. The BIOS, FPGAs, and the firmware on the cards may be updated. If the power is removed during these upgrades, the cards may become unusable. -
Page 14: Upgrading With The Pp833 Upgrade Kit
Upgrading the CTP2000 Series Device to CTPOS 7.x Upgrading with the PP833 Upgrade Kit To remove or install the CompactFlash card for the CTP2000 Series with the new PP833 processor: Power down the system through either the menu or CTPView. - Page 15 Chapter 2: Upgrading the CTP2000 Series Device to CTPOS 7.x The CompactFlash script runs an application that checks for the proper BIOS and upgrades the BIOS if necessary. The application checks for proper FPGAs on the cards and daughter cards installed and upgrades them as necessary.
-
Page 16: Migrating From A Previous Operating System
Upgrading the CTP2000 Series Device to CTPOS 7.x Migrating from a Previous Operating System You should see the following upgrade script output when you complete the steps described in “Upgrading with the PP310 Upgrade Kit” on page 11. The upgrade script output produced when you complete the steps described in “Upgrading with the PP332... -
Page 17: Figure 4: Compactflash Adapter With Compactflash Card Inserted
Chapter 2: Upgrading the CTP2000 Series Device to CTPOS 7.x Press Enter. For the PP310, the BIOS configuration is updated and the device reboots. The following upgrade script output is displayed for the PP310. The upgrade script output for the PP332 is very similar, and you must respond to the same prompts. - Page 18 Upgrading the CTP2000 Series Device to CTPOS 7.x Please remove the old flash, hit return when finished. Migrating system ID to new flash. * The system will reboot when finished. INIT: Sending processes the TERM signal Gathering system information. * Please wait this could take up to 45 seconds.
- Page 19 Chapter 2: Upgrading the CTP2000 Series Device to CTPOS 7.x NOTE: For the PP332 processor, the BIOS version is 2.14 and a BIOS upgrade is not required. Press Enter to reboot the system. Copyright © 2015, Juniper Networks, Inc.
-
Page 20: Preparing A System For Firstboot Using Ctpos 7.0R1 And Later
Upgrading the CTP2000 Series Device to CTPOS 7.x Preparing a System for Firstboot Using CTPOS 7.0R1 and Later You should see the following upgrade script output when you complete the steps described in “Upgrading with the PP310 Upgrade Kit” on page 11. - Page 21 Chapter 2: Upgrading the CTP2000 Series Device to CTPOS 7.x Press Enter. The BIOS configuration is updated, the device reboots, and the following output is displayed: Gathering system information. * Please wait this could take up to 45 seconds. Found:...
-
Page 22: Registering Your Upgrade
Installing or Replacing CTP2000 DRAM Memory Modules in the PP310 or PP332 CPU on page 23 Restoring BIOS Defaults for the CTPOS 7.0R1 and Later Upgrade (PP310) on page 24 Installing or Removing a CTP2000 Series CompactFlash Card on page 26 Copyright © 2015, Juniper Networks, Inc. -
Page 23: Servicing The Ctp2000 Cpu
Chapter 2: Upgrading the CTP2000 Series Device to CTPOS 7.x Servicing the CTP2000 CPU This topic describes how to remove the CTP2000 CPU from the chassis for service or upgrade, and how to return the CPU to the chassis. Follow proper antistatic procedures when you perform the following procedures. -
Page 24: Restoring Bios Defaults For The Ctpos 7.0R1 And Later Upgrade (Pp310)
Upgrading the CTP2000 Series Device to CTPOS 7.x Release the memory module by using your thumb to raise the end of the memory module to the angle shown in Figure 5 on page NOTE: Figure 5 on page 24 shows the PP310 CPU. The memory module is removed and replaced in the same manner for the PP332 CPU. -
Page 25: Figure 6: Jumper Setting For Restoring Bios Defaults
Chapter 2: Upgrading the CTP2000 Series Device to CTPOS 7.x Figure 6: Jumper Setting for Restoring BIOS Defaults To restore default BIOS settings: Remove the CPU from the CTP2000 device chassis. See “Servicing the CTP2000 CPU” on page Locate the BIOS reset pins, which are shown as two black circles inside a figure 8 and captioned as CMOS Clear. -
Page 26: Installing Or Removing A Ctp2000 Series Compactflash Card
You can then remove or install the CompactFlash card inthe flash socket. Reinstall the PP833 PRC card into the chassis, and securethe retaining screws. To remove or install the CompactFlash card for the CTP2000 series with the PP310 and PP332 processors: Power off the unit.
