HT66FM5340
Brushless DC MCU with Pre-driver

Absolute Maximum Ratings

Supply Voltage (V
Supply Voltage (V
High Voltage Input Voltage .............................................................................. V
Input Voltage ..................................................................................................... V
Storage Temperature ..................................................................................................... -50°C to 125°C
Operating Temperature ................................................................................................... -40°C to 85°C
I Total ...................................................................................................................................... -80mA
OH
I Total ....................................................................................................................................... 80mA
OL
Total Power Dissipation ........................................................................................................... 500mW
Note: These are stress ratings only. Stresses exceeding the range specified under "Absolute
Maximum Ratings" may cause substantial damage to the device. Functional operation of the
device at other conditions beyond those listed in the specification is not implied and prolonged
exposure to extreme conditions may affect device reliability.

D.C. Characteristics

For data in the following tables, note that factors such as oscillator type, operating voltage, operating
frequency, pin load conditions, temperature and program instruction type, etc., can all exert an
influence on the measured values.

Operating Voltage Characteristics

Symbol Parameter
Operating Voltage – HIRC
V
DD
Operating Voltage – LIRC

Standby Current Characteristics

Symbol Standby Mode
SLEEP Mode
I IDLE0 Mode – LIRC
STB
IDLE1 Mode – HIRC
Note: When using the characteristic table data, the following notes should be taken into consideration:
1. Any digital inputs are setup in a non-floating condition.
2. All measurements are taken under conditions of no load and with all peripherals in an off state.
3. There are no DC current paths.
4. All Standby Current values are taken after a HALT instruction execution thus stopping all instruction
execution.
Rev. 1.00
, V ) ........................................................................................V
CC1 CC2
) .................................................................................................V
DD
Test Conditions
f =f =20MHz
SYS HIRC
f =f /64=312.5kHz
SYS HIRC
f =f =32kHz
SYS LIRC
Test Conditions
V Conditions
DD
5V LIRC & LVR on, LVD off, WDT on
5V f on
SUB
5V f on, f =f
SUB SYS HIRC
11
-0.3V to V
SS
SS
Min. Typ.
4.5 —
3.15 —
3.15 —
Min. Typ.
— 60
— 5
=20MHz — 400
-0.3V to 15V
SS
-0.3V to 6.0V
SS
+0.3V
CC1
-0.3V to V +0.3V
DD
Ta=-40°C~85°C
Max. Unit
5.5
V
5.5
5.5 V
Ta=-40°C~85°C
Max. Unit
100 μA
10 μA
500 μA
December 07, 2018
