Installation Instructions
BHL Freewheeling
Trim Retrofit
For Trim purchased prior to August 2019
8200 Series
WARNING
This product can expose you to lead
which is known to the state of California
to cause cancer and birth defects or other
reproductive harm. For more information
go to www.P65warnings.ca.gov.
1-800-727-5477 • www.sargentlock.com
Copyright © 2019, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or
in part without the express written permission of SARGENT Manufacturing Company is prohibited.
A8259A 07/19

Advertisement

Table of Contents
loading

Related Manuals for Assa Abloy Sargent BHL 8200 Series

Summary of Contents for Assa Abloy Sargent BHL 8200 Series

  • Page 1 Installation Instructions BHL Freewheeling Trim Retrofit For Trim purchased prior to August 2019 8200 Series WARNING This product can expose you to lead which is known to the state of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65warnings.ca.gov.

  • Page 2: Table Of Contents

    BHL Freewheeling Trim Retrofit 8200 Series Installation Instructions Table of Contents Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Package Contents .

  • Page 3: Tools Required

    BHL Freewheeling Trim Retrofit 8200 Series Installation Instructions Tools Required • Phillips Screwdriver (# 2) • Torx Tamper Resistant Driver (T-20) • Torx Tamper Resistant Driver (T-10) • Hex Key Driver 5/64" Package Contents 82-1359 Behavior Health Lever 01-1440 Reuse from existing BHL Trim Set Screw(1/4-28 x 7/8”) 82-0347 Spindle Spring 81-0790 (Used with 1/8”...

  • Page 4: Assemble Spring Cartridges Into Bhl Levers

    BHL Freewheeling Trim Retrofit 8200 Series Installation Instructions Assembly (cont .) Assemble Spring Cartridges into BHL Levers Finished Lever Assembly Press spring cartridge assemblies into levers so that top of spring cartridge is flush or slightly below flush to lever’s top surface.

  • Page 5: Assemble Outside Adapter Plate And Rose

    BHL Freewheeling Trim Retrofit 8200 Series Installation Instructions Assembly (cont .) Assemble Outside Adapter Plate and Rose • Insert two (2) mounting posts into adapter plate. (Figure 6) • Install rose using four (4) security torx screws. Note: Tighten screws evenly. Adapter and Plate Assembly with Mounting Posts Rose Assembly...

  • Page 6: Install Outside Trim

    BHL Freewheeling Trim Retrofit 8200 Series Installation Instructions Installation (cont .) Install Outside Lever Assembly (cont .) RH Outside LH Outside • Insert spindle into bushing; ensure that spindle is inserted no more than ¾" deep. • Use spindle to rotate bushing clockwise into outside lever hole.

  • Page 7: Install Inside Bhl Rose Assembly

    BHL Freewheeling Trim Retrofit 8200 Series Installation Instructions Installation (cont .) Install Inside BHL Rose Assembly Attach inside rose assembly to inside adapter plate using four (4) security Torx screws. Tighten screws evenly. (Figure 12) LHR Inside Shown IMPORTANT Screw oriented towards latch Security Torx Screws Figure 12 Install Inside Lever Assembly...
  • Page 8 SARGENT Manufacturing Company 100 Sargent Drive New Haven, CT 06511 USA 800-727-5477 www.sargentlock.com Founded in the early 1800s, SARGENT ® is a market leader in locksets, cylinders, door closers, exit devices, electro-mechanical products and access control systems for new construction, renovation, and replacement applications.
