GCC LaserPro E200
User Manual
Version: 3.0
Release Jul., 2020
4F., No.236, Fude 2nd Rd., Xizhi Dist., New Taipei City 22151, Taiwan 886-2-6616-6692 Fax:886-2-2694-6875

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LaserPro E200 Series and is the answer not in the manual?

Questions and answers

Related Manuals for GCC Technologies LaserPro E200 Series

Summary of Contents for GCC Technologies LaserPro E200 Series

  • Page 1 GCC LaserPro E200 User Manual Version: 3.0 Release Jul., 2020 4F., No.236, Fude 2nd Rd., Xizhi Dist., New Taipei City 22151, Taiwan 886-2-6616-6692 Fax:886-2-2694-6875...
  • Page 2 Release Note Version Release Date Change Apr., 2020 First version Jul., 2020 Second version Sep., 2020 Third Version 3.0-1 Nov., 2020 Remove Chapter 5.2-7 E200 User Manual I...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Chapter 1 Safety .............................. 5 1.1 Principles of a CO 2 Laser ........................ 6 1.2 Safety Ratings ............................ 6 1.3 The Safety Interlock System ......................6 1.4 Safety Labels ............................6 1.5 Safety Measures ..........................10 1.6 Operating Environment ........................11 1.7 Noise Test ............................
  • Page 4 7.2 SmartJOB Software Operation ..................... 48 7.2.1 User interface introduction ....................48 7.2.2 Functional Introduction ......................48 7.2.3 Trace Image Files ........................ 49 7.2.4 Engraving & Cut by SmartJOB (workflow) ............... 52 7.3 The LaserPro E200 Print Driver ....................56 7.3.1 Page Setup and Orientation ....................
  • Page 5 9.2 Maintaining the Worktable and Motion System ................93 9.2.1 Cleaning the Worktable and Motion System ..............93 9.2.2 Lubrication of the X / Y Rails ....................94 9.3 Cleaning the Optics System ......................95 9.3.1 Cleaning the Mirrors ......................95 9.3.3 Removing and Cleaning the Focal Lens ................

  • Page 6: Chapter 1 Safety

    Chapter Safety Principles of CO2 Laser Safety Ratings The Safety Interlock System Safety Labels Safety Measures Operating Environment...

  • Page 7: Safety Ratings

    1.1 Principles of a CO Laser LASER is the acronym for Light Amplification by Stimulated Emission of Radiation. A CO laser works by electrically stimulating the molecules within a carbon dioxide gas mixture. When focused through a lens, this highly-intense, invisible beam will vaporize many materials. Depending on the speed and intensity of the projected beam, a CO laser may be used to engrave or cut through a wide variety of materials.
  • Page 8 In compliance with CDRH standards, the required warning labels are affixed at the time of manufacture to the LaserPro E200 in the appropriate locations. These labels are not to be modified in any way or removed for any reason. Please familiarize yourself with the specific labels and their locations on the machine. Below is a list of all the safety labels and their locations on the machine.
  • Page 9 CDRH Label This label indicates the class level of CDRH. CE Label This label identifies the classification of the Model in accordance with IEC 60825-1. It is located on the rear of the machine’s cabinet. Aperture warning stickers (mirror): This label indicates the laser path. Normally you can find this label inside of machine or laser exit. Please take extra caution of this area when you conduct maintenance or operate machine.
  • Page 10 Warning Label Warning Label is written with all the necessary information to be aware of during operation. Invisible laser radiation when door open and interlock failed. Avoid eye or skin exposure direct to laser radiation. Do not leave the machine unattended during operation. Please clean the bearings and motion system tracks every day.

  • Page 11: Safety Measures

    1.5 Safety Measures • LASER RADIATION WARNING: Exposure to laser radiation may result in physical burns and severe eye damage. Proper use and regular maintenance of this machine is important to the safety of all people in the immediate area. •...

  • Page 12: Operating Environment

    1.6 Operating Environment Please follow the guidelines when considering a suitable location to set the LaserPro E200. Improper work environments may lead to operational malfunction and/or unsafe working conditions. The LaserPro E200 should be placed and operated in a standard office-type environment. •...

  • Page 13: Chapter 2 Unpacking

    Chapter Unpacking Unloading & Unpacking...

  • Page 14: Unloading And Unpacking

    Unloading and Unpacking The GCC LaserPro E200 is shipped in one crate that contains machine, software, and all of the necessary accessories. The following section shows detailed step-by-step instructions for unpacking and assembly the accessory to workstation. WARNING More than one person may be needed when loading and unloading the shipping crate in order to avoid body injury or damage to the machine.
  • Page 15 Remove the packing foam on the top. Remove the side-cover carton. Release the four safety blocks that hold the machine in place.
  • Page 16 6) Take out the water chiller and the accessory box. Now you can take out the machine. Lastly take out the laser materials which we enclose within E200.

  • Page 17: Chapter 3 Mechanical Overview

    Chapter Mechanical Overview Front View Right View Left View Rear View Water Chiller Front View Water Chiller Right View Water Chiller Left View Water Chiller Rear View...

  • Page 18: Front View

    Please take some time to familiarize yourself with this section regarding the mechanical overview of the LaserPro E200. References will be made back to the different parts of the LaserPro E200 in later sections. 3.1 Front View 3.2 Top View...

  • Page 19: Right (Profile) View

    3.3 Right (Profile) View 3.4 Left (Profile) View...

  • Page 20: Rear View

    3.5 Rear View...

  • Page 21: Water Chiller Front View

    3.6 Water Chiller Front View...

  • Page 22: Water Chiller Right View

    3.7 Water Chiller Right View 3.8 Water Chiller Left View 3.9 Water Chiller Rear View...

  • Page 23: Chapter 4 Machine Setup

    Chapter Machine Setup Water Chiller Setup E200 Desktop Laser Engraver Setup...

  • Page 24: Water Chiller Setup

    Water Chiller Setup 1) Find two cables & two water hoses from the accessory box. 2) Connect the power cable from the machine to the water chiller.
  • Page 25 1) Connect the signal cable from the machine to the water chiller. 2) Connect the water hose from the machine to the water chiller. a. E200 machine “Water Out” to water chiller “Inlet”. b. E200 machine “Water in” to water chiller “Outlet”...
  • Page 26 3) Fill distilled water into water supply inlet, make the water level be between the max and min limitation line. NOTE: Please use distilled water ONLY 4) E200 Water Chiller setting up is completed.

  • Page 27: E200 Machine Setup

    E200 Machine Setup 1. Take out the wifi dongle from the zip bag in the accessory box. 2. Insert the wifi dongle to the USB port on the back of E200 machine. 3. Connect the power cable and power on E200 machine.
  • Page 28 4. Press on the "Quick Boot Button" on the front of machine. 5. Remove the Camera Cover to let the camera is ready to capture the table. Remove the camera cover. 6. E200 setting up is simply and easy. * To use the extra facility, the power voltage shall be the same as the main power.

  • Page 29: Chapter 5 Software Setup

    Chapter Software Setup Recommended Computer Configuration SmartJOB E200 Installation E200 Driver Installation...

  • Page 30: Recommended Computer Configuration

    5.1 Recommended Computer Configuration SmartJOB E200 software was designed to work best using both Windows and MAC system with the following minimum requirements Computer Configuration Intel Pentium, 1GHz or above DRAM 1GB RAM or above CDROM One CD-ROM disk drive 1 GB of free hard drive space SVGA Super VGA display (1204 x 768 min.
  • Page 31 2) Click “Next” 3) Clip “Launch SmartJOB”, and clip Finish.
  • Page 32 4) The SmartJOB will automatically open when installation is finished. 5) Take out the Notification from accessory box. 6) Go to "Help" --> "Activate" from the menu bar and key in name and activate code to activate the software.

  • Page 33: E200 Driver Installation

    5.3 E200 Driver Installation Please visit GCC website – download area to download E200 Print Driver and User Manual. https://www.gccworld.com/download.php?sid=driver...

  • Page 34: Chapter 6 Connection Setup

    Chapter Connection Setup Machine Connection Setup Computer Assign the Connection Method Connection Troubleshooting...

  • Page 35: Machine Connection Setup

    6.1 Machine Connection Setup The LaserPro E200 can communicate with a computer through a Wi-Fi, USB Port or LAN Port connection interface. Please see below steps for each connection method. 6.1.1 Wi-Fi Connectivity Setting on E200 by Wi-Fi connectivity, please download the small app - E200 Connection Wizard from GCC download area https://www.gccworld.com/download.php?sid=other 1) Connect E200 with your computer by the USB cable.
  • Page 36 5) Choose the WiFi connection. 6) WiFi Setting is complete.

  • Page 37: Computer Assigns The Connection Method

    6.1.2 Ethernet Connectivity 1) Connect Ethernet cable between router and machine. 2) Turn ON machine. 3) Connect computer to Internet through Ethernet or Wi-Fi 6.1.3 USB Connection 1) Connect USB cable between machine and computer. 6.2 Computer Assigns the Connection Method 6.2.1 For SmartJOB Wi-Fi / LAN 1) Make sure your computer is connected to the same WiFi (SMC) as E200 does...
  • Page 38 4) Select the “Wi-fi / LAN” on the drop-down menu of Connection 5) Click on “Setup” button to open the setup window 6) Click the “Scan Device” button, the software will search and show the list automatically.
  • Page 39 7) Click the machine you want to connect and click “OK” button. 8) Wi-Fi/LAN Connection setting is completed. 1) Open SmartJOB, and go to “settings” on the menu bar...
  • Page 40 2) Select “USB” button and click “OK” button to open the setting window. USB Connection setting is completed. 6.2.2 For E200 Print Driver Wi-Fi / LAN  1) Go to “Control panel” “Devices and Printers” 2) Double click “E200” printer driver to open the printer driver window...
  • Page 41  3) Click “Printer” “Properties” on the menu bar to open the properties window. 4) Click the “Pen” tab and click “Port” button to open the Port Configure window 5) Select “LAN/Wifi” button and click “OK” button to open the setting window...
  • Page 42 6) Double click your machine from the Device List and the setting is complete. Pleae check your serial number of the machine to make sure the connection is correct if you have many machines. 7) WiFi/LAN Connection setting is completed. ...
  • Page 43 4) Click the “Pen” tab and click “Port” button to open the Port Configure window 5) Select “USB” button and click “OK” button to open the setting window 6) “USB” Connection setting is completed.

  • Page 44: Connection Troubleshooting

    6.3 Connection Troubleshooting For above Wi-Fi connection, E200 Connection Wizard will select the available IP automatically, if you want to appoint specific IP, please follow below steps. 1) Connect the USB cable between the machine and computer. 2) Open E200 Connection Wizard program. You can find the program in the installation CD. Note: Please make sure that the program can find the “Device”...
  • Page 45  Static IP for Wi-Fi 4) After entering those parameters, click the “Set” button to save the setting. 5) The setting is completed.

  • Page 46: Chapter 7 Operating The Gcc Laserpro E200

    Chapter Operating the GCC LaserPro E200 How to use Focus Tool SmartJOB Software Operation The LaserPro E200 Print Driver E200 Touch Panel Operation...

  • Page 47: How To Use Focus Tool

    7.1 How to use focus tool Use the focus tool to do manual focus. a. Place the focus tool this way to do manual focus with nozzle. b. Place the focus tool this way to do manual focus without nozzle. 1.
  • Page 48 2. Place the focus tool between the material and the carriage, the following picture shows the focus distance with the nozzle installed. 3. Place the focus tool between the material and the carriage, the following picture shows the focus distance with the nozzle installed.

  • Page 49: Smartjob Software Operation

    7.2 SmartJOB Software Operation 7.2.1 User interface introduction Table Mat: Display the real-time table and object view QR Code reading state bar: Show the barcode reading state. File List: Show the file history (Max. 4pcs) Materials Parameter Datebase: Allow users to choose the processing parameter according to different materials.

  • Page 50: Trace Image Files

    7.2.3 Trace Image Files SmartJOB allows you to import image files (ai., bmp., jpg., gif., png. etc… formats) and will trace the image for cutting. Please note, results may vary depending on the source image file. To trace an image, choose "Trace Image" from the File menu, or click the Trace toolbar button. Step 1 Select Trace Image button on the toolbar to open the setting window.
  • Page 51 Input Settings Choose an Image: click “Choose an image…” button. The program can accept most files (.bmp, .jpg, .gif, .png). Image Settings Mode: choose which tracing mode you would like to do. Monochrome - will trace as if the image is a black and white image. Contrast: this value will determine the cutoff to whether parts of the image should be traced.
  • Page 52 Single Color - choose a specific color from the image to trace. To choose a color, click the color button, and then click on the preview image to choose a color. Output Settings Smooth: higher values will result in a smoother trace. Detail: lower values will remove smaller shapes Single Line Threshold: this can be used if you are tracing images that have outlines shapes that are not filled solid to prevent having double lines.

  • Page 53: Engraving & Cut By Smartjob (Workflow)

    7.2.4 Engraving & Cut by SmartJOB (workflow) Step 1 Place the GCC Material to E200 machine. NOTE: Every material piece which comes with E200 has a specific barcode on the surface of the material. When removing protection foil, please do NOT remove the QR code sticker.
  • Page 54 Step 3 After loading the file, please click “Capture Table” to take a photo of working table and E200 camera will scan the barcode which stick on the GCC materials. Step 4 Once “Capture Table”, camera will also scan the barcode sticker which is on the material too.
  • Page 55 Step 5 Go to file list, and click the right mouse button, SmartJOB will set up the parameter according to different materials automatically. Step 6 Parameter setting is ok, press print to process the engraving job.
  • Page 56 Step 7 If you have adjusted the parameter, you can save the parameter into the material database and name it yourself. Step 8 The parameter will be saved to “Customer Parameter Database” as below Step 9 Here you can also do the export parameter data or import data.

  • Page 57: The Laserpro E200 Print Driver

    7.3 The LaserPro E200 Print Driver With the LaserPro E200 print driver successfully installed, you will need to adjust the printer and page size default settings before you can begin editing and completing jobs. By doing so, you will be setting the work area in your graphics software to match the LaserPro E200’s worktable area.
  • Page 58 CorelDRAW Example (Page Setup and Orientation) The following is an example of how to set the Page Setup and Orientation in the graphics software. CorelDRAW is the designated graphics software used for this example. For other graphics software, you will need to access the corresponding Page Setup page. From the primary menu, click LAYOUT →...

  • Page 59: Color Management

    7.3.2 Color Management LaserPro driver uses pen color settings to control laser engraver engraving and cutting parameters. In addition to having your Page Setup and Orientation properly set in your graphics software, you will also need to make sure Color Management is DISABLED prior to working with the LaserPro E200 Print Driver From your graphic software’s Color Management page: Disable Color Management or set Color Management to Off.

  • Page 60: Using The Laserpro E200 Print Driver

    7.3.3 Using the LaserPro E200 Print Driver Now after you have properly set the Page and Layout and Color Management of your graphics software, you are ready to configure the details of your actual job through the LaserPro E200 Print Driver.

  • Page 61: Using The Laserpro E200 Print Driver >> Pen Page

    7.3.4 Using the LaserPro E200 Print Driver >> Pen Page Mode Setting [DEFAULT SETTING: Black & White] You can select four primary mode settings, depending on your application or results you would like to achieve. Black & White: Select this mode when using clipart images or drawings with several colors, shades of gray, or many outlines.
  • Page 62 The Black & White mode interprets the processed image by the varying colors and shades. For the best results, we suggest you convert the image to a grayscale image with your graphics software prior to engraving in the Black & White mode.
  • Page 63 Mirror [DEFAULT SETTING: Unselected] Checking this box will automatically engrave your image with a mirrored effect. This setting will flip the image along the Y-axis from left to right and vice-versa. When engraving a stamp, via the stamp mode, the stamp image needs to be engraved in reverse (mirrored) for the final stamp to be correctly laid out.
  • Page 64 NOTE The LaserPro E200 print driver cannot store more than 5 pen colors or different laser parameter settings per file. Speed (Pen Page) [DEFAULT SETTING: 40] The speed slider controls the laser’s speed during operation (engraving speed) with settings ranging from 0.1 –...
  • Page 65 edges when cutting. Lower PPI settings may reduce this effect, but may result in a serrated looking edge. If you drag the PPI slider to the maximum, the value will change to X. This completely disables the PPI control and turns on the laser continuously without pulsing. This disables the power ramp functionality, which automatically controls the PPI depending on the speed of the laser carriage (such as vector cutting around the corner of a square).With PPI to X.
  • Page 66 Image Output Direction [DEFAULT SETTING: Top To Bottom] These selections allow you to control the direction in which the system processes an engraved image. • Top To Bottom: Selecting this will force the system to process the current task by moving the laser carriage from the top to the bottom of the image (rear end to front end of the work table).
  • Page 67 Halftone [DEFAULT SETTING: Dithering] This option controls the way a raster-engraved image is processed. The “digital image to engraved output” process can be processed via two methods: Dithering or Error Diffusion. Each offer additional output options yielding different output effects, style, and quality. •Dithering: Interprets and outputs the raster engraving via the dithering method.
  • Page 68 The following diagram is an example of the raster effects when using the different diffusion types. Floyd Stucki Jarvis There is no "correct" or "best" setting when using the Raster options. The most appropriate settings will be based on a variety of factors: your design, the material you are engraving on, the results you wish to achieve, etc.
  • Page 69 Pitch (Stamp Page) Your stamp will be a reversed image composed of engraved depressions and ridges. Think of these ridges as the "contact sections" of the stamp. If the ridges of these contact sections are too thin, they may break. The Pitch setting allows you to increase the width of the ridge base, hence creating more stable "contact sections"...

  • Page 70: E200 Touch Panel Operation

    7.4 E200 Touch Panel Operation 7.4.1 Navigation Chart of E200 Touch Panel...

  • Page 71: Main Work Page

    7.4.2 Main Work Page When the LaserPro E200 is powered on, the machine will perform a series of safety checks and initializing routines. The Touch Panel screen will display the GCC copyright, LaserPro logo, and machine initialization pages before going to the main work page. Door - The door light will illuminate when the top lid are open or improperly closed.

  • Page 72: Function Page

    7.4.3 Function Page • Machine Setting Page – this page allows you to do LED light setting, reset and offset tuning. • Advanced Option – this page allows you to view laser status and origin position. • Information Page – this page allows you to view information regarding the system such as the GCC logo, machine name, firmware version, and other information.

  • Page 73: File Management Page

    7.4.4 File Management Page To manage the edited file to adjust / set up the parameters File Information Page File Edit Page 7.4.5 File Management Page >> File Edit Raster Page The File Edit Raster Page allows you to edit the raster power and speed settings. These settings correspond to the same settings found on the LaserPro E200 driver.

  • Page 74: File Management Page >> File Edit Vector Page

    • Raster Power: 0.0% - 100% • Raster Speed: 0.1% - 100% 7.4.6 File Management Page >> File Edit Vector Page The File Edit Vector Page allows you to edit the vector pen, vector power, vector speed, and vector PPI, and power ramp settings for the selected job.

  • Page 75: Machine Setting

    7.4.7 Machine Setting The Machine Setting Page allows you to access and modify various machine settings, including: Others (Air Delay), Offset tuning, LED light setting, Reset. 7.4.8 Other Page >> Air Delay Setting Page...

  • Page 76: Offset Tuning

    The Air Delay setting allows you to specify the delay in seconds of the SmartAIR air-assist after the point of laser firing. • Air Delay: 1-100 seconds Depending on the material you are engraving with, your laser settings, and the desired results, please experiment with the air delay to achieve your desired results.

  • Page 77: Led Light Setting

    7.4.10 LED Light Setting The LED setting page allows you to set the lightness of LED, lever: 1~5 7.4.11 Reset Page The Reset Page will restore machine settings back to factory default. Press ENTER to confirm the change, and restart the machine.

  • Page 78: Machine Information Page

    7.4.12 Machine Information Page The Machine Information Page allows you to view information regarding the system such as the GCC logo, machine name, firmware version, and other information.

  • Page 79: Advanced Option

    7.4.13 Advanced Option The advanced page allows you to enable different usages for the laser machine, such as Laser Status – to reset laser firing time, Origin Position setting. 7.4.14 Advanced Option >> Laser Status Reset Laser Firing time, you will have to enter the password to reset the Laser Fired time...

  • Page 80: Advanced Option >> Origin Position

    7.4.15 Advanced Option >> Origin Position The Origin Position Page allows you to reset the origin position by defining the current X-axis and Y-axis positions. You will need to reset the origin position if you change the ruler of the working table.

  • Page 81: Chapter 8

    Chapter Optional Items Fume Extraction System Air Compressor Rotary Attachment...

  • Page 82: Fume Extraction System Option

    When purchasing the LaserPro E200 from your local authorized GCC distributor, you will be provided a chance to purchase optional items to enhance your experience with your system. If anytime after the purchase of your LaserPro E200, would you like to purchase any optional item, please contact your local authorized GCC distributor.

  • Page 83: Air Compressor Option

    8.2 Air Compressor Option Specifically designed for laser engravers, the air compressor utilizes an oil-free diaphragm. The air compressor helps eliminate harmful and potentially damaging moisture from the laser optics, maximizing laser optic life. In addition the air compressor provides the optimal air flow to the SmartAIR nozzles to minimize flaming, suppress working temperatures, and blow away dust and particle byproducts generated from the laser process.
  • Page 84 3) Connect a ¼ " tubing to the air tube fastener valve on the air compressor. NOTE It is important that the ¼ " air tubing has clean, straight cuts on each end. Jagged or slanted cuts will not produce adequate sealing capabilities. 4) Take the unattached end of the ¼...
  • Page 85 OPERATION: Switch on the air compressor unit and make sure that the airflow regulator on the air assist valve is opened (turn clockwise to increase the airflow, counter-clockwise to decrease the airflow). The air nozzle under the laser head should emit a steady flow of air. With the SmartAIR nozzle and air compressor properly installed and operating, all configurations and settings relating to air-assist functions are controlled through the LaserPro print driver and hardware control panel.

  • Page 86: Rotary Attachment Option

    8.3 Rotary Attachment Option The rotary attachment option provides the E200 with the ability to engrave on cylindrical or spherical objects. In addition to the standard X, Y, Z axis, the rotary attachment allows for a fourth axis which rotates your object 360° to allow for engraving on cups, wine glasses, and even spherical objects. Work Piece Limitations Maximum Length 250 mm (10 inches)
  • Page 87 Follow the procedure to exchange the front fixture and back fixture: Remove the two screws holding the fixtures. Exchange the front fixture and back fixture as below picture, After Before NOTE Align the origin point to the flat top of shaft then tighten the first screw against it, following to tighten the second screw.
  • Page 88 INSTALLATION: a. Uninstall the grid cutting table 1) Remove the four screws from the grid cutting table. NOTE: There are four hand screws to be removed. 2) Take out the grid cutting table as shown below 3) E200 - Grid cutting table uninstallation is completed.
  • Page 89 b. Installation of E200 Rotary Attachment 1) Turn off the power of the laser engraver 2) Open the front panel of the machine, lower the working platform to its bottom 3) When placing the rotary attachment on the working table, the rotary attachment can only apply the small conical fixtures to work with small objects of diameters.
  • Page 90 CAUTION If your work piece is small, please apply 4" focal lens for operation to prevent the lens carriage from colliding with the rotary attachment. 4) Prepare the graphic you would like to engrave with the rotary attachment, and print it to GCC laser print driver, and go to “Paper”...
  • Page 91 7) Go back to other pages of GCC Laser Print Driver to set up laser parameters like speed, power, and dpi etc. (refer to Chapter V of user manual for print driver operation details) and click “OK” to print your design to the laser machine. 8) Despite the dummy-proof installation design, please ensure that the rotary device is installed correctly before turning on the machine...

  • Page 92: Chapter 9

    Chapter Basic Maintenance Suggested Cleaning and Maintenance Supplies Maintaining the Work table and Motion System Cleaning the Optics System...

  • Page 93: Suggested Cleaning And Maintenance Supplies

    Keeping your LaserPro E200 clean and well maintained will ensure quality output, consistent reliability, and extended product life. Smoke, dust or residue build-up inside the laser system or the mechanical components can cause a reduction in the laser power, irregularities in the motion system, reduced product life cycle, and a host of other avoidable problems.

  • Page 94: Maintaining The Worktable And Motion System

    *The recommended lens cleaner is Eclipse Cleaning System Solution from Photographic Solutions or HPLC grade Methanol. Search “Eclipse Cleaning System Solution” on Amazon or eBay to get the solution locally. http://www.amazon.com/Photographic-Solutions-ECDCS-Cleaning-Solution/dp/B0000AUR1I Eclipse Cleaning System Solution 9.2 Maintaining the Worktable and Motion System 9.2.1 Cleaning the Worktable and Motion System Clean the working table and the motion system on weekly basis through the following steps: 1) Turn the power off and unplug the E200 before cleaning.

  • Page 95: Lubrication Of The X / Y Rails

    9.2.2 Lubrication of the X / Y Rails In order to keep the motion system running smoothly, the X / Y rails of the motion system will need lubrication on a weekly basis. Use a small amount of light grade machine oil or PS2 grease to a paper or cotton towel and apply to the rails.

  • Page 96: Cleaning The Optics System

    9.3 Cleaning the Optics System 9.3.1 Cleaning the Mirrors After you have removed each mirror, you will want to inspect each mirror for scratches, smoke residue, or debris. If any residue or debris is present, use the following steps to clean the mirror.

  • Page 97: Removing And Cleaning The Focal Lens

    9.3.3 Removing and Cleaning the Focal Lens 1) Remove the nozzle from the E200 carriage. 2) Remove the tube by releasing the hand screw.
  • Page 98 3) Carefully pull out the focal lens. Clean the focal lens with a cotton swab and lens cleaner solution. Be sure to clean both sides of the focal lens (DO NOT apply any pressure or other cleaning solutions to the lens surface).

  • Page 99: Chapter 10 Appendix

    Chapter Appendix GCC LaserPro E200 Specification Sheet...

  • Page 100: Gcc Laserpro E200 Specification Sheet

    10.1 GCC LaserPro E200 Specification sheet LaserPro E200 Work Area 20 x 12.9in. (510 x 330mm) Maximum Part Size 20.4 x 13.4 x 0.78in.(520 x 340 x 20 mm) (with grid cutting (WxLxH) table) 19.8 x 13.4 x 2.99in.(505 x 340 x 76 mm) (remove grid cutting table) CCD Camera Standard...
