- Page 1 Installation Instructions GuardPLC Digital Input/Output Module Catalog Number 1753-IB20XOB8 Topic Page Important User Information About the Module General Safety Install the Module Mount the Module Ground the Module Wire the Module Make Connections for Safety-related Communication Reset Push Button Status Indicators Specifications Additional Resources...
-
Page 2: Important User Information
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment. -
Page 3: About The Module
Do not touch connectors or pins on component boards. • Do not touch circuit components inside the equipment. • Use a static-safe workstation, if available. • Store the equipment in appropriate static-safe packaging when not in use. Rockwell Automation Publication 1753-IN003C-EN-P - June 2010... -
Page 4: Install The Module
Follow these steps to install the module. 1. Mount the module to a DIN rail. 2. Ground the module. 3. Wire the module. 4. Make connections for safety-related communication. This publication describes these steps in detail. Rockwell Automation Publication 1753-IN003C-EN-P - June 2010... -
Page 5: Mount The Module
DIN rail materials (for example, aluminum or plastic) that can corrode, oxidize, or are poor conductors, can result in improper or intermittent grounding. Secure DIN rail to mounting surface approximately every 200 mm (7.8 in.) and use end-anchors appropriately. Rockwell Automation Publication 1753-IN003C-EN-P - June 2010... -
Page 6: Wire The Module
L- terminals are internally connected, so you can daisy-chain 24V DC power from the module to other devices in the panel by using the remaining terminal. ATTENTION: Do not reverse the L+ and L- terminals or damage to the module will result. There is no reverse polarity protection. Rockwell Automation Publication 1753-IN003C-EN-P - June 2010... - Page 7 31 32 33 34 35 36 37 38 39 40 41 42 (—) (—) 13 14 15 16 23 24 Connection of Voltage Supply to Input Device Light Curtain (or any Safety Input) Rockwell Automation Publication 1753-IN003C-EN-P - June 2010...
- Page 8 14. Digital inputs (DI) are connected to these terminals. Terminal Number Designation Function Sensor supply for inputs 1…4 Digital input 1 Digital input 2 Digital input 3 Digital input 4 Reference pole Rockwell Automation Publication 1753-IN003C-EN-P - June 2010...
- Page 9 Digital input 20 Reference pole LS+, not L+, should be used for short-circuit protection. Each LS+ features individual short-circuit and EMC protection that make it important to use LS+ for only its four related inputs. Rockwell Automation Publication 1753-IN003C-EN-P - June 2010...
- Page 10 With an overload, one or all of the outputs are turned off. When the overload is eliminated, the outputs are activated again according to the specified value. Although the external line of an output is not monitored, a short-circuit will be indicated. Rockwell Automation Publication 1753-IN003C-EN-P - June 2010...
- Page 11 Example: Connecting Actuators to the Outputs Inductive loads can be connected without a protection diode on the load. However, Rockwell Automation strongly recommends that a protection diode be fitted directly to the load to suppress any interference voltage. A 1N4004 diode is recommended.
-
Page 12: Reset Push Button
The next time you cycle power, these settings will be restored to the last values stored into nonvolatile memory. This means that either the settings prior to the reset will be restored, or if any settings were changed after the reset, those new settings will still be in effect. Rockwell Automation Publication 1753-IN003C-EN-P - June 2010... -
Page 13: Status Indicators
Boot Loader unable to load operating system or unable to start COMM operating system loader. Module status can be interrogated through the programming software. For more information, refer to the GuardPLC System User Manual, publication 1753-UM001. Rockwell Automation Publication 1753-IN003C-EN-P - June 2010... -
Page 14: Specifications
1 Signal 0 Signal Voltage: 5V DC max, Current consumption: 1.5 mA max (1 mA @ 5V) Switching point Typically 7.5V Sensor supply 5 x 20V / 100 mA @ 24V short-circuit proof Rockwell Automation Publication 1753-IN003C-EN-P - June 2010... - Page 15 7 A max with exceeding shut down of all outputs with cyclic reconnecting Response overload Shut down of the concerned output with cyclic reconnecting Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1. Rockwell Automation Publication 1753-IN003C-EN-P - June 2010...
- Page 16 10V rms with 1 kHz sine-wave 80% AM • from 150 kHz…80 MHz IEC 61000-4-6 • Damped Oscillatory Wave Immunity ±1 kV line-earth (CM) on signal ports • • IEC 61000-4-12 ±1 kV line-earth (CM) on power ports Rockwell Automation Publication 1753-IN003C-EN-P - June 2010...
- Page 17 : up to and including SIL 3 according to IEC 61508 and PLe (Cat. 4) according to ISO 13849-1 See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details. When used with specified firmware revisions. Rockwell Automation Publication 1753-IN003C-EN-P - June 2010...
-
Page 18: Additional Resources
General guidelines for installing a Rockwell Automation industrial system Guidelines, publication 1770-4.1 You can view or download publications at http://www.rockwellautomation.com/literature. To order paper copies of technical documentation, contact your local Rockwell Automation distributor or sales representative. Rockwell Automation Publication 1753-IN003C-EN-P - June 2010... - Page 19 GuardPLC Digital Input/Output Module Rockwell Automation Publication 1753-IN003C-EN-P - June 2010...
-
