Installation

Placement
1.
The Dimplex Electric Fireplace does
not require any special venting.
Make sure there is clearance for air
circulation beneath the unit and at
least ¹/2" (12 mm) behind it.
CAUTION: Do not install the fireplace
directly on carpet or similar surfaces
which may restrict air flow.
2.
Install the unit in an opening with the
following dimensions:
Model DF28
A 27" (686 mm) wide
B 23 ¹/8" (587 mm) high
C 8" (203 mm) deep
Model DF26
A 24 ³/8" (619 mm) wide
B 18 ¹/2" (470 mm) high
C 8" (203 mm) deep
Dimplex Fireplace DF28L-PRO / DF28DWC-PRO / DF26L-PRO / DF26DWC-PRO
3.
If installing the unit in an existing
fireplace opening, seal all drafts and
vents with a non-fibrous insulation
material to prevent any chimney
debris from falling onto the unit. Do
not install into an existing fireplace
opening that is prone to dampness.
B
C
A
7
