Service Manual
26" Self Trimming Fireplace with 3 Stage Remote
Model Number:
DF2690
MOD: 0
Dimplex North America Limited
1367 Industrial Road
Cambridge ON Canada N1R 7G8
1-800-668-6663
www.dimplex.com
In keeping with our policy of continuous product development, we reserve the right to make changes without notice.
REV
PCN
DATE
00
11047
Nov 14, 08
7400010000rev00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DF2690 and is the answer not in the manual?

Questions and answers

Related Manuals for Dimplex DF2690

Summary of Contents for Dimplex DF2690

  • Page 1 DF2690 MOD: 0 DATE 11047 Nov 14, 08 Dimplex North America Limited 1367 Industrial Road Cambridge ON Canada N1R 7G8 1-800-668-6663 www.dimplex.com In keeping with our policy of continuous product development, we reserve the right to make changes without notice.

  • Page 2: Table Of Contents

    Table Of Contents Page 1 Operation Page 3 Exploded Parts Diagram Page 4 Parts List Page 4 Wiring Diagram Page 5 Front Glass Replacement Page 5 Light Bulb Replacement Page 6 Mirror Replacement Page 6 Main Power On/Off Switch Replacement Page 7 Manual Selection Switch Replacement Page 7...

  • Page 3: Operation

    Operation NOTE: The heater may emit a slight, harmless odor when first used. This odor is a normal condition caused by This section will explain the function of each convenient initial heating of internal heater parts and will not occur control.
  • Page 4 1. Ensure that power is supplied through main service FIGURE 4 panel. 2. Locate manual controls. (FIGURE 1) 3. Activate main power switch. 4. Press and hold the Manual Selection Switch in the “ I “ position for 5-10 seconds. (The second red indicator light will flash).

  • Page 5: Exploded Parts Diagram

    Exploded Parts Diagram...

  • Page 6: Parts List

    16. Remote Receiver 3000430800RP 7. Flame Action Control 3000240500RP c/w Transmitter c/w Potentiometer 17. Terminal Block 4000070100RP 8. Light Dimmer Control 3000250100RP 18. Flicker Rod 5901250100RP c/w Potentiometer 19. Upper Light Harness 2500400300RP 9. Cord Set 4100040200RP Wiring Diagram - DF2690...

  • Page 7: Front Glass Replacement

    Front Glass Replacement Upper Bulb Requirements: A quantity of two (2) chandelier or candelabra bulbs with an If unit was operating prior to servicing allow at least 10 E-12 (small) socket base, 15 watt rating are required. minutes for light bulbs and heating element to cool off to avoid accidental burning of skin.

  • Page 8: Mirror Replacement

    5. Pull the front edge of the plastic ember bed or plastic 7. Push the mirror up from underneath to clear the frame grate up and forward until the rear tab releases from and remove. the ledge located at the bottom of the mirror. 8.

  • Page 9: Manual Selection Switch Replacement

    FIGURE 8 FIGURE 10 Manual Selection Screws To Remove Switch Wire Connectors (3) FIGURE 9 Main ON/OFF Switch Retainer Clips (one top, one bottom) 7. Reassemble in the reverse order as above. Light Dimmer Replacement Retainer Clips If the fireplace was operating prior to servicing allow at (one top, one bottom) least 10 minutes for light bulbs and heating element to cool off to avoid accidental burning of skin.

  • Page 10: Flame Action Control Replacement

    on its back), four (4) screws in the front directly under potentiometer through the front of the panel and the control panel; and two (2) screws on the bottom of remove from inside the cabinet. the fireplace (see FIGURE 8, Page 7). The bottom 7.

  • Page 11: Thermostat Control Replacement

    4. Locate Flicker Rod and Flicker Motor in the base 11. Discard old Flicker Motor. assembly. (FIGURE 13) 12. Pick up new Flicker Motor and cut wire leads to 3 1/2” 5. Gently pull the Flicker Rod to the right as far as long with wire cutters.

  • Page 12: Remote Control Replacement

    5. Locate and disconnect the two (2) power cord wire FIGURE 15 connections: one from the bottom of the two (2) connectors on the Main On/Off Switch; the other on the Flame Speed Control board, noting their original locations. (FIGURE 16) 6.

  • Page 13: Heater Assembly Replacement

    disconnect the six (6) wiring clips noting their original and continue to reconnect and reassemble the fireplace locations. in reverse order as described above. 11. Disconnect the three (3) wire leads from the Manual Heater Assembly Replacement Selection Switch. (the wires are hard-wired to the Remote Control Receiver) (FIGURE 17) If the fireplace was operating prior to servicing allow at 12.
  • Page 14 FIGURE 20 Heater Assembly Top Panel Heating Element Terminal Block Wires Leading to Bottom Assembly noting all of their original positions. 6. Turn the top panel over and while supporting the Heater Assembly and panel in one hand, remove the five (5) heater mounting screws, noting the center screw is of a larger diameter.
