Owner's Manual
Model Numbers:
DF2603
Serial Number
Model Number
Part Number
Valued Customer,
Thank you and congratulations for purchasing a Dimplex
electric fireplace. Over the years, valuable memories
will occur around the warmth and comfort of your hearth.
Thank you for allowing our product to be the backdrop
for those special
moments.
Quality checked by:
7204820100rev04

Advertisement

Table of Contents
loading

Summary of Contents for Dimplex DF2603

  • Page 1 Owner’s Manual Model Numbers: DF2603 Quality checked by: Serial Number Model Number Part Number Valued Customer, Thank you and congratulations for purchasing a Dimplex electric fireplace. Over the years, valuable memories will occur around the warmth and comfort of your hearth. Thank you for allowing our product to be the backdrop for those special moments. 7204820100rev04...
  • Page 2 • Are the light bulbs loose? (To check, follow the instructions for replacing the light bulbs under the maintenance section of this manual.) 2. The heater may emit a slight, harmless odor when first used. This odor is a normal condition caused by the initial heating of internal heater parts. 3. The information regarding the model of your unit can be found on the rating plate located on the top left hand corner of the unit. See page 6 for an illustration on how to locate the rating plate. 4. If you have any questions or concerns regarding the operation of your fireplace, contact Dimplex customer service at 1-888-DIMPLEX (1-888-346-7539)
  • Page 3: Table Of Contents

    CONTENTS Important Instructions ....PAGE 4 Model and Serial Number Information..PAGE 6 Site Selection and Preparation ..PAGE 6 Fireplace Insert Installation ... PAGE 10 Operation .
  • Page 4: Important Instructions

    IMPORTANT INSTRUCTIONS Retain This User’s Guide For Future Reference When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1. Read all instructions before using the electric fireplace. 2. The heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. The trim around the heater outlet becomes hot during heater operation. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the unit. 3. Extreme caution is necessary when any heater is used by or near children or invalids and whenever the unit is left operating and unattended. 4. Always unplug the electric fireplace when not in use. 5. Do not operate with a damaged cord or plug, or if the heater has malfunctioned, or if the electric fireplace has been dropped or damaged in any manner. Return fireplace to an authorized service facility for examination, electrical or mechanical adjustment, or repair. 6. Do not use outdoors. 7. The electric fireplace is not intended for use in bathrooms, laundry areas and similar indoor locations. Never locate heater where it may fall into a bathtub or other water container. 8. Do not install the fireplace directly on carpet or a similar surface which may restrict air circulation beneath the unit. 9. Do not run the cord under carpeting. Do not cover cord with throw rugs, runners, or the like. Arrange cord away from traffic area and where it will not be tripped over.
  • Page 5: Save These Instructions

    other use not recommended by the manufacturer may cause fire, electric shock or injury to persons. 15. To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other). The plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way. Avoid the use of an extension cord. Extension cords may overheat and cause a risk of fire. If you must use an extension cord, the cord must be No. 14 AWG minimum size and rated no less than 1875 Watts. 16. Do not burn wood or other materials in the electric fireplace. 17. Do not strike the glass front. 18. Always use a certified electrician should new circuits or outlets be required. 19. Always use properly grounded, fused and polarized outlets. 20. Disconnect all power supply before performing any cleaning, maintenance or relocation of the unit. 21. When transporting or storing the unit and cord, keep in a dry place, free from excessive vibration and store so as to avoid damage. SAVE THESE INSTRUCTIONS NOTE: Procedures and techniques that are considered important enough to emphasize. CAUTION: Procedures and techniques which, if not carefully followed, will result in damage to the equipment. WARNING: Procedures and techniques which, if not carefully followed, will expose the user to the risk of fire, serious injury, illness or death.
  • Page 6: Model And Serial Number Information

    Figure 1 Model Number Part Number SERIAL No. Serial Number Site Selection and Preparation This section provides easy step by step instructions for selecting a location and preparing the site to install the fireplace into: • Existing fireplace • New wall construction • Dimplex mantel surround kit or custom made mantel surround ! NOTE: The fireplace insert comes completely assembled and wired. Some tools may be required to prepare the site and assembly/install the trim. The dimensions of the fireplace insert are 26 inches (66 cm) wide X 22 ½ inches (57.2 cm) high X 12 inches (30.5 cm) deep (Figure 2). You should allow ¼ inch (0.6 cm) around the fireplace insert for ease of installation. This fireplace does not require any venting.
  • Page 7 Figure 2 26” (66 cm) 22 ½” (57.2 cm) 12” (30.5 cm) Rubber Feet Air Circulation Areas CAUTION: Clearance for air circulation beneath the fireplace insert is provided by three (3) rubber feet (Figure 2). Do not install the fireplace insert directly on carpet or similar surfaces which may restrict air circulation. If installing the fireplace in a carpeted area, place a one-piece, solid, flat surface under the fireplace insert. Ensure that all three (3) of the insert’s feet rest securely on this surface. Existing Fireplace 1. Seal all drafts and vents with non-fibrous insulation materials to prevent chimney debris from falling into the fireplace insert. Do not install into an existing fireplace that is prone to leaks or dampness.
  • Page 8 on a regular basis when Figure 3 the heater is operating. Additional appliances on the same circuit may exceed the current rating of the circuit breaker. WARNING: To prevent personal injury you should hire a professional to cap the chimney flue or cut a hole in the existing fireplace for wiring. If you return your existing Cord fireplace to its original use (example wood burning), it should be inspected by the local building department prior to use to reduce the risk of fire and personal injury. New Wall Construction (Figure 4) 1. Select a suitable location that is not susceptible to moisture and is away from drapes, furniture and high traffic. NOTE: The fireplace insert must be installed on a hard surface.
  • Page 9 Figure 4 23” (58.4 cm) 26 ½” (67.3 cm) 12” (30.5 cm) Figure 5 Figure 6 Outlet Cord WARNING: Construction and electrical outlet wiring must comply with local building codes and other applicable regulations to reduce the risk of fire, electrical shock and injury to persons. Mantel Surround Kit or Custom Made Mantel Surround 1. Select a suitable location that is not susceptible to moisture and is away from drapes, furniture and high traffic.
  • Page 10: Fireplace Insert Installation

    2. Place the fireplace in the desired location to see how it will look in the room. 3. For ease of electrical hook up you may wish to locate the fireplace near an existing outlet (refer to NOTE 1). 4. Store the fireplace in a safe dry and dust free location. 5. Assemble the mantel surround kit (refer to the mantel assembly instructions) or construct the custom surround with an opening of 26 ½ inches wide X 23 inches high (67.3 cm wide X 58.4 cm high) allowing a depth of 12 inches (30.5 cm) (Figure 4). WARNING: Do not attempt to wire your own new outlets or circuits. To reduce the risk of fire, electric shock or injury to persons, always use a licensed electrician. Fireplace Insert Installation This section provides easy step by step instructions for installation of your fireplace. 1. Install Trim Kit to front of fireplace by positioning trim then pushing straight forward against the fireplace. 2. Make sure the unit is switched Off (refer to Operating instruction section). 3. Plug the fireplace into a 15 Amp/120 Volt outlet. If the cord does not reach you may use a extension cord rated for a minimum of 1875 Watts.
  • Page 11: Operation

    Figure 7 Insert Wall or Trim Mantel Push Figure 9 Figure 8 Grill Open Here Shims Operation This section will explain the function of each convenient control. 1. To access the controls, open the upper grill by pulling, near the top right hand side, forward and down (Figure 9). 2. To locate controls refer to Figure 10. 3. To conceal the controls during the operation, return the grill to its original upright position. WARNING: The centre and left hand side of the grill will get hot when the heater is operating. Take care to always grasp the grill on the right hand side.
  • Page 12 Figure 10 control is bypassed. The “II” position is for operating the unit with the provided remote control. When in “II” position the unit is operated with the ON and OFF buttons of the remote control. When the switch is in the center position “O” the unit is off. B. Flame Action Control Turn the flame action control knob to adjust the flame speed to the desired level. C. Interior Light Control Turn the interior light control knob to increase or decrease the brightness of the interior light. D. Heater On/Off Switch Turn heater on or off. E. Heater Thermostat Control To adjust the temperature to your individual requirements, turn the thermostat control clockwise all the way to turn on the heater. When the room reached the desired temperature, turn the thermostat knob counter clockwise until you hear a click. Leave in this position to maintain the room temperature at this setting. For additional heat, turn...
  • Page 13: Remote Control

    Resetting the Temperature Cutoff Switch This unit is equipped with a thermostat which controls the temperature of the room. It does this by turning the heater on and off. The heater is protected with a safety device to prevent overheating. Should the heater overheat, an automatic cut out will turn the heater off and it will not come back on without being reset. It can be reset by switching the Main On/Off Switch to “O” (Off) and waiting five (5) minutes before switching the unit back on. CAUTION: If you need to continuously reset the heater, unplug the unit and call your local dealer. Remote Control Figure 11 The fireplace is supplied with an integrated On/Off remote control. NOTE: Ensure that the fireplace’s Three Position Button Switch is set to the Remote Battery Control setting (“II”...
  • Page 14: Maintenance

    NOTE: You will have only 10 seconds to perform this last step. Failure to do so will result in these steps needing to be followed again. Maintenance WARNING: Disconnect power before attempting any maintenance or cleaning to reduce the risk of fire, electric shock or damage to persons. Light Bulb Replacement WARNING: Allow at least five (5) minutes for light bulbs to cool off before touching bulbs to avoid accidental burning of skin. Light bulbs need to be replaced when you notice a dark section of the flame or when the clarity and detail of the log exterior disappears. There are two (2) bulbs at the top of the opening which illuminate the log set exterior, and four (4) bulbs under the log set which generate the flames and embers. Helpful Hints It is a good idea to replace all light bulbs at one time if they are close to the end of their rated life. Group replacement will reduce the number of times you need to open the unit to replace light bulbs. Tool Requirements: Slot screwdriver NOTE: Before replacing lamps unnecessarily, ensure that they are not simply loose or that the brightness control is not adjusted to low setting (see item C in operation section). To open the light bulb area: 1. Remove the trim by pulling straight forward. 2. Hold the glass in place while removing the retaining clip from the upper center of the firebox (Figure 12A).
  • Page 15 Figure 12 Retaining Clip Removing Replacing Holding Glass Glass Glass bumped, struck or dropped. Care must be taken when handling the glass. Lower Light Bulb Requirements Quantity of four (4) clear chandelier or candelabra bulbs with an E-12 (small) socket base, 60 Watt rating. CAUTION: Do not exceed 60 Watts per lamp. To replace the bottom light bulbs: 1. Lift up the front edge of the log until it clears the front tabs. Pull out until the rear tab clears the back ledge, then lift out (Figure 13). Figure 13 Figure 14 Back Ledge Log Ember bed Lifting out Rear Front Side Section Edge Ember Bed...
  • Page 16: Glass Cleaning

    5. Replace the log by pushing it down and in until it rests against the mirror (Figure 14). Upper Light Bulb Requirements Quantity of two (2) clear chandelier or candelabra bulbs with an E-12 (small) socket base, 15 Watt rating. Please refer to the label adjacent to the upper lamps for the correct wattage for your model. CAUTION: Do not exceed 25 Watts per lamp. To replace the top light bulbs: 1. Locate the two (2) upper bulbs inside the firebox at the top. 2. Examine the bulbs to determine which bulbs require replacement. 3. Hold the socket while unscrewing the bulb. 4. Hold the socket while screwing in the new bulb. To reassemble lamp area 1. Replace the glass and hold it in place at the top (Figure 12B). 2. Fasten retaining clip to hold glass in place (Figure 12C). Glass Cleaning The glass is cleaned in the factory during the assembly operation. During shipment, installation, handling, etc., the clear door may collect dust particles; these can be removed by dusting lightly with a clean dry cloth. To remove fingerprints or other marks, the clear door can be cleaned with a damp cloth. The clear door should be completely dried with a lint free cloth to prevent water spots.
  • Page 17: Warranty

    Warranty Products to which this limited warranty applies This limited warranty applies to the following applicable models of your newly purchased Dimplex electric fireplace 6901181300 and to newly purchased Dimplex fireplace surrounds (mantels) and trims. This limited warranty applies only to purchases made in any province of Canada except for Yukon Territory, Nunavut, or Northwest Territories or in any of the 50 States of the USA (and the District of Columbia) except for Hawaii and Alaska. This limited warranty applies to the original purchaser of the product only and is not transferable. Products excluded from this limited warranty Light bulbs are not covered by this limited warranty and are the sole responsibility of the owner/purchaser. Products purchased in Yukon Territory, Nunavut, Northwest Territories, Hawaii, or Alaska are not covered by this limited warranty. Products purchased in these States, provinces, or territories are sold AS IS without warranty or condition of any kind (including, without limitation, any implied warranties or conditions of merchantability or fitness for a particular purpose) and the entire risk of as to the quality and performance of the products is with the purchaser, and in the event of a defect the purchaser assumes the entire cost of all necessary servicing or repair.
  • Page 18 For products (other than surrounds (mantels) and trims) for the period ending at midnight on the first anniversary of the date of first purchase, Dimplex will in its sole discretion either repair or replace such defective product or part without charge. If Dimplex is unable to repair or replace such product or part, or if repair or...
  • Page 19 Such costs shall not be the responsibility of Dimplex. • On-site or in-home services not provided under this warranty may be performed at the purchaser’s specific request and expense at Dimplex’s then-current rates for such services. What Dimplex and its dealers and service agents are also not responsible for IN NO EVENT WILL DIMPLEX, OR ITS DIRECTORS, OFFICERS, OR AGENTS, BE LIABLE TO THE PURCHASER OR ANY THIRD PARTY, WHETHER IN CONTRACT, IN TORT, OR ON ANY OTHER BASIS, FOR ANY INDIRECT, SPECIAL, PUNITIVE, EXEMPLARY, CONSEQUENTIAL, OR INCIDENTAL LOSS, COST, OR DAMAGE ARISING OUT OF OR IN CONNECTION WITH THE SALE, MAINTENANCE, USE, OR INABILITY TO USE THE PRODUCT, EVEN IF DIMPLEX OR ITS DIRECTORS, OFFICERS, OR AGENTS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH LOSSES, COSTS OR DAMAGES, OR IF SUCH LOSSES, COSTS, OR DAMAGES ARE FORESEEABLE. IN NO EVENT WILL DIMPLEX, OR ITS OFFICERS, DIRECTORS,...
