If any parts are missing or damaged, contact your Dealer before
starting installation. DO NOT install a damaged kit. Be sure to
also reference the appliance Installers Guide.
Approvals
The flexible duct in this Smart-Wall™ (SMART-WALL-B)
TV kit is manufactured and marked to the requirements of
UL-181, Class I air duct.
Introduction
The SMART-WALL-B TV kit conveys warm air from the
appliance through an air duct to remote locations in the
same room or other rooms of the building. See Figure 1.
This kit is only approved for use with the following models:
COSMO32-IFT
RAVE3012-IFT
COSMO42-IFT
RAVE4013-IFT
COSMO32-IFT-B
RAVE32-IFT-B
COSMO36-IFT-B
RAVE36-IFT-B
COSMO42-IFT-B
RAVE42-IFT-B
NOTICE:
DO NOT install a GFK-160A fan kit in a
fireplace equipped with the SMART-WALL-B TV kit. The
GFK-160A fan could cause the TV to overheat.
The purpose of this kit is to keep the area above the appli-
ance at a temperature that is within the flat screen style TV
manufacturer's specified maximum operating temperature.
The ability of the SMART-WALL-B TV Kit to accomplish
this purpose is expressly dependent upon the following
conditions.
The manufacturer's specified maximum operating tem-
perature (for the TV unit being used in this application)
being no less than 100 degrees Fahrenheit (consult
your manufacturer to determine the maximum operating
temperature for your TV unit);
If the specified maximum operating temperature
for your TV unit is less than 100 degrees Fahren-
heit, do not use that particular TV in this application.
The back of the TV unit (after installation on a wall
mounted bracket) having and maintaining not less than
a 3-inch gap between the back of the TV unit and the
wall. This is the gap between the back of the TV and
the wall which is vital for proper air and temperature
circulation.
The ambient temperature of the room is maintained at
75 degrees Fahrenheit or less.
The SMART-WALL-B TV Kit and the TV must be installed
and operated in strict compliance with all other appli-
cable installation and operation instructions for this kit.
SMART-WALL-B TV Kit
- Installation & Operation Instructions -
JADE32IN
JADE42IN
JADE42IL
JADE32IN-B
JADE42IN-B
JADE42IL-B
Hearth & Home Technologies • SMART-WALL-B Air Duct Kit • 4086-348 Rev. D • 3/20
Hearth & Home Technologies does not guarantee that a
user's TV will safely operate long-term in conditions not
strictly in compliance with those described in the previous
paragraph.
Preliminary Preparation
Contents of kit:
DESCRIPTION
20 ft. Length of 6 in. Insulated
Round Duct
Fan Housing Assembly
Junction Box
SMART-WALL-B Control Module
Air Register
Register Adaptor Frame-Thick
Appliance Duct Collar
Duct Adaptor (Round to Oval)
Accessory Cable (20 ft.)
Power Harness
IFT-RC400 Remote Control
IFT-RF Module
IFT-ACM Module
IFT-ACM Cable
Please note, while the SMART-WALL-B TV Kit, when in-
stalled and used properly will allow most TVs to operate
above the fireplace appliance without damaging the TV,
operating a TV at the higher end of the manufacturer's
maximum operating temperature range, may and likely
will have some impact on the life span of the TV appliance
compared to operating it at normal ambient temperatures.
The SMART-WALL-B uses a control module that must
be used with the IntelliFire™ Touch control system. The
SMART-WALL-B blower turns on and operates for two
minutes before the ignition sequence begins. The SMART-
WALL-B blower remains on for 20 minutes after the appli-
ance is turned off to remove residual heat so the TV does
not overheat.
NOTICE: The Cold Climate feature of the IntelliFireTouch
control system is not functional when the SMART-WALL-B
kit is installed.
TV installation must follow the guidelines in Figure 14 for
the SMART-WALL-B to function properly.
SERVICE PART NO.
659-200
659-001A
659-122
2326-180
659-150
SRV695-125
SRV659-125
659-129
4086-349
2326-136
SRV2326-110
2326-120
2326-150
SRV2326-152
