6.4.4.2 "Display mode" submenue
In the "Display mode" submenue, you configure the representation of the measured values
and additional information on the display.
With the menue item "Screen layout" you configure the information that is displayed and its
layout. Up to five values can be displayed at the same time. In the additional menue en-
tries "1st value" to "5th value" you define the contents of the placeholders in the layout.
The various layouts as well as the possible content of the values are described in Chapter
6.2.4.
6.4.5 "Measurement/Output" menue
Configure the measured value as well as the current output in the "Measurement/output"
menue.
Menue entry
Damping
Measuring rate
Output function
Lower Range Value
Upper Range Value
Output table
Alarm current
Lower current limit
Upper current limit
Independent from the setting of the upper and lower current limit, the set measuring range
always corresponds to a current range of 4...20 mA.
BA_072_2020-02_10.00 Pressure transmitter PASCAL Ci4
Description
Setting the damping of the output signal
Setting the measuring rate (20 or 100 Hz), except for devices with
differential pressure cell, type CI4x4x
Setting the output function (linear, inverse, square root, table)
Setting the pressure value that shall correspond to 4 mA (start of
range)
Setting the pressure value that shall correspond to 20 mA (end of
range)
Specifying the points for the table function
Select the alarm current: High (>21 mA) or low (<3.6 mA)
Limit of the lower output current (3.8...4.0 mA)
Limit of the upper output current (20...21 mA)
Table13: "Measurement/Output" menue
