II 4)
LEDs in Panel III
III 1) Display of supply frequency 50 Hz
III 2) Display of supply frequency 60 Hz
III 4) Display: Weld current measurement has been carried out.
LEDs in Panel IV
Display of weld current for tongs, push spot welding, stud welding,
QUICKSPOT
Minimum displayable current: 3000 A =
Maximum displayable current
Display of weld current for Airpuller, washer welding, high-speed
planishing hammer, annealing
Minimum displayable current:
Maximum displayable current: 2500 A =
11.4
11.5
Subject to technical alterations without notice.
ELEKTRON Bremen GmbH
Tel + 49 421 54906-0 · Fax +49 421 54906-19 · vertrieb@elektron-bremen.de · www.elektron-bremen.de
400 V power inlet
– With 230 V power supply unit:
CAUTION switch the unit OFF immediately!
Supply voltage is too high.
Display of weld current in Panel IV.

Manual tool selection

In an emergency or for service examination, it is possible to bypass
automatic tool recognition.
– Switch the unit OFF.
– Connect the tool to the unit.
– Switch the unit ON, depressing the tool key.
– Select the tool required with the keys AB.
– Reset on tool change or switch the unit off.
Operation panel malfunction
In the case of a malfunction in the operating panel, that is to say there is no
reaction when a button is pressed, if LED displays illuminate incorrectly, etc.,
switch the unit OFF and switch ON again after approx. 2 sec. This will clear the
malfunction

