HTML Operation, cont'd
Creating or deleting a tie
Make or break a tie as follows:
1.
2.
N If you lose track of the input and output associated with a specific button, stop
N To tie an input to all outputs, click that input's input number.
3.
6-14 CrossPoint 450 Plus and MAV Plus Switchers • HTML Operation
Click the Video Only, Audio Only, or Video & Audio button to select video,
audio, or both for switching (audio breakaway or audio follow). Each mouse
click on a button toggles the other two buttons off.
Move the mouse over the matrix of input and output selection buttons. Click
a button to:
• Create a pending tie (if a tie does not exist) of the input and output
associated with that button.
• Create a pending untie (if a tie exists) of the input and output associated
with that button.
A "P" (for pending) appears in the button.
the mouse pointer over a button. A field pops up (as shown on figure 6-11) that
identifies the input and output for that button.
Click the Take button to make the configuration changes or the Cancel button
to abandon the configuration changes.
