I/O control buttons
Primary functions
Secondary functions
Front panel
locks
RGB delay
Resets
Port
configuration
Audio
You must specify video, audio, or both when you are creating or viewing a
configuration. This is done with the RGBHV button (CrossPoint switchers) or
Video button (MAV Plus switchers) (
g
RGBHV (CrossPoint 450 Plus) button or Video (MAV Plus) button — The
RGBHV (CrossPoint 450 Plus switchers) or Video (MAV Plus video switchers)
button has one primary function (•) and five secondary (❏) functions:
• Selects and deselects video for a configuration that is being created or
viewed and lights green to indicate that video is available for configuring
or for viewing.
With the Enter button and Audio button, selects between front panel
❏
locks (Lock mode 2 and Lock mode 0). See "Setting the front panel locks
(Executive modes)" on page 3-43.
With the Audio button, toggles the front panel lock on or off. See "Setting
❏
the front panel locks (Executive modes)" on page 3-43.
With the Audio button, commands the front panel system reset. See
❏
"Performing a system reset from the front panel" on page 3-44.
(Systems with CrossPoint 450 Plus Wideband switcher BMEs) Selects
❏
the RGB delay mode, in which you can set the RGB delay. See "Setting
RGB delay (systems with wideband BMEs)" on page 3-27.
Selects the RS-232 protocol for the RS-232/RS-422 port in Serial Port
❏
Configuration mode and indicates the selection. See "Selecting the rear
panel Remote port protocol and baud rate" on page 3-46.
CrossPoint 450 Plus and MAV Plus Switchers • Operation
Action
Select video.
Indication Green when selected
RGBHV
or
Action 1 With Enter, select Lock mode 2 or toggle between
Action 2 Select Lock mode 1 or toggle between mode 2 and
Action Select RGB Delay mode.
Indication
Blinking: selected
Action Perform a system reset
Action Select RS-232.
Indication
Blinking: selected
Action
Indication
) and Audio (
g
Select audio.
Red when selected
VIDEO AUDIO
mode 0 and mode 2.
mode 1.
Select RS-422.
Blinking: selected
Select Audio mode.
Blinking: selected
) buttons.
h
3-9
