Summary of Contents for TSI Instruments Quest Edge 7
- Page 1 Quick Start Guide Quest™ Edge 7 Personal Noise Dosimeter...
-
Page 2: Checking The Equipment
Checking the Equipment If your instrument was sent to you in a storage case, remove all the packaging and become acquainted with the following equipment so you can quickly get started with your noise studies. NOTE: Depending on the accessories you selected, the dosimeter may have the following components. For the charging dock, you will either have an EdgeConnect1 or an EdgeConnect5. - Page 3 Quest™ Edge Dosimeter Display and Keypad Windscreen and microphone LED Indicator ▪ Red - indicates dose exceeded the alarm level ▪ Amber - dosimeter stopped ▪ Green - dosimeter measuring Display (measurement view shown) ▪ View data and various indicators Side Button ▪...
-
Page 4: Turning On / Turning Off
Turning On / Turning Off 1) To turn on the dosimeter, press the On/Off button. The splash screen will appear indicating the firmware version. After the splash screen disappears, the screen will be in the measurement view. 2) To turn off the dosimeter, press and hold the On/Off button. A “3, 2, and 1” countdown will appear as the dosimeter is powered off. - Page 5 Calibrating It is recommended to calibrate your dosimeter before you run your study(ies) and after your study(ies) to ensure highly accurate measurement results. The steps below address how to calibrate for either a pre or post study. Calibrating the dosimeter 1) Remove the windscreen from the dosimeter by twisting and pulling the black ring (do not pull on the foam).
- Page 6 Setting up the Quest™ Edge 7 Dosimeter The EG7 model comes equipped with four customizable user setups. You have the option to customize the parameters for threshold values, exchange rate values, filtering, an upper limit value, and a criterion level. The EG7 model also has the 1/1 octave capability that can be enabled via DMS.
-
Page 7: Overview Of Running A Study
Overview of Running a Study On Quest™ Edge 7 dosimeters, with the introduction of the Pause functionality, the time between Run and Stop is considered a session. If a user does a Run, Pause, Run, Pause, Stop, the data in DMS will show two studies within a Session. - Page 8 Additional Features (See User Manual for Specific Use Instructions) The Octave Band Graph displays the SPL (Sound Pressure Level) and L or L values/graph for each frequency band in a given audio spectrum (Note: refer to pages 34-35 in the DMS manual for more information on this feature).
-
Page 9: Charging Your Dosimeter
Charging your Dosimeter How to Charge 1) Plug in the power adapter to the EdgeConnect charging dock (see power adaptor below). ▪ The EdgeConnect’s lower LED will appear solid when powered on. 2) Slide the dosimeter downward onto the hook of the EdgeConnect until it clicks. - Page 10 Common Noise Dosimeter Terms Criterion Level (CL) - expressed in decibels (dB), it is the maximum allowable accumulated noise level that results in 100% dose. Regional noise standards specify criterion level. Dose - expressed in percent, it is the percent of the maximum exposure that has accumulated over the run time.
- Page 11 Peak level - the highest instantaneous sound level that the microphone detects. Unlike the Max Level, the peak is detected independently of the slow or fast response time the unit is set for. Response Time (Fast, Slow, Impulse) - how quickly the circuitry responds to changing noise levels.
- Page 12 TSI, the TSI logo are registered trademarks of TSI Incorporated in the United States and may be protected under other country’s trademark registrations. TSI Incorporated - Visit our website www.tsi.com for more information. North America and Asia Pacific Europe, Middle East, and Africa Telephone: +1 800-680-1220 (USA) Telephone: +49 241-52303-0...
