Main screen view and description
The user navigates in the menu structure using the buttons located next to the display
1. Display
2. ▲- „up" „plus" – it is used to view the menu options and increase the value while editing
parameters. During standard operation the button is used to switch between diff erent
zones parameters.
3. ▼ - „down" „minus" - it is used to view the menu options and decrease the value
while editing parameters. During standard operation the button is used to switch between
diff erent zones parameters.
4. MENU button – it is used to enter the controller menu and confi rm the new settings
5. EXIT button – it is used to exit the menu and cancel the settings
1
12
2
3
4
5
