Adding the IF4U to CCW

The 2080sc-IF4U is configured for CCW (Connected Components
Workbench) using the PLUGIN_READ and PLUGIN_WRITE instructions
for generic plug-in modules.
The configuration, input data, and status structures discussed in the
sections above, are stored at different memory locations in the module.
The following table lists the memory location offset for each parameter
which is used when configuring the PLUGIN_READ, WRITE, and INFO
instructions.
Table 7 (Parameter Offset)
Parameter
MOD_ID_LO
MOD_ID_HI
VENDOR_ID_LO
VENDOR_ID_HI
PRODUCT_TYPE_LO
PRODUCT_TYPE_HI
PRODUCT_CODE_LO
PRODUCT_CODE_HI
MOD_REV_LO
MOD_REV_HI
MOD_STATUS
SYNC_DATA_LATCH
CONFIG_IN0_LO
CONFIG_IN0_HI
CONFIG_IN1_LO
CONFIG_IN1_HI
CONFIG_IN2_LO
CONFIG_IN2_HI
CONFIG_IN3_LO
CONFIG_IN3_HI
INPUT_DATA_0_LO
INPUT_DATA_0_HI
INPUT_DATA_1_LO
INPUT_DATA_1_HI
INPUT_DATA_2_LO
INPUT_DATA_2_HI
INPUT_DATA_3_LO
INPUT_DATA_3_HI
CJC_DATA_LO
CJC_DATA_HI
OC_STATUS
U_O_RANGE_STATUS
Publication 0100189-04 Rev. C
Offset
(Dec)
0
1
2
3
4
5
6
7
8
9
16
26 Writing 0xA5 to this register triggers input data latch
32
33
34
35
36
37
38
39
48
49
50
51
52
53
54
55
56
57
80
81
Comments
Module ID
Vendor ID
Minor revision, 1-255
Major revision, 1-127
Module status register
(see Table 6)
Channel Configuration
Registers
Input Data
(Format is 16-bit signed integer)
Open-circuit status
Under/over range status
