Operating Procedures
Inspecting Parts
Materials Needed:
•
PG-6000 gage
•
Part
Inspecting parts using the PG-6000 involves placing the gage on a part in order to compare the nominal
functional diameter of the gage to the actual functional diameter of the part.
1. After zeroing the PG-6000 gage, pull the
retraction lever and position the lower thread
roll in the threads of the part.
2. Using the lower thread roll as a pivot, seat the
upper thread roll in the threads of the part.
i
a
m
e
t
e
r
G
a
g
e
O
p
e
i
a
m
e
t
e
r
G
a
g
e
O
p
e
•
•
r
a
t
i
o
n
M
a
n
u
a
l
r
a
t
i
o
n
M
a
n
u
a
l
Gauging tolerances (Thread Disk for Windows software)
Inspection report
19
